RX-9928 Temperature Sensing Bulb Type Thermostat Performance and Life Testing Machine I. Overview According to the standards: GB14536.1, GB14536.10, IEC60730-1, this equipment is suitable for the life testing of temperature sensing bulb type thermostats used in various appliances such as refrigerators, freezers, water dispensers, compressors, etc., as well as the testing machine for the temperature/action response time of TPC thermistors. The test bench is composed of a high and low temperature tank and a detection and control system. The load for the life test is to be equipped separately. II. Technical Indicators for Performance Testing: l Equipment Control Power Supply: 220V, 50Hz l Number of Test Stations: 3 l Working Temperature Range: -30℃ to +350℃, Temperature Accuracy: Not greater than ± (0.5% of the reading + 0.5℃); l Constant Temperature Mode: Low temperature tank (alcohol) and high temperature tank (oil bath) l Temperature Non-uniformity in the Detection Area: Not greater than ±1℃; l Detection Resolution: 0.1℃; III. Life Testing: l Test Speed: Approximately 6 times per minute for the fastest products l Number of Tests: Can be set from 1 to 9,999,999 l Intelligent Discrimination Function: An alarm will be issued when the switch is adhered, there is continuous connection or disconnection, or when the set number of test times is reached. l Without test load, with an interface
