**ZH-TPE09Pro-1AQF Visual Thermometer**

**[Product Introduction]**

The ZhiPinHui Thermal Imaging E-Series Visual Thermometer is compact, lightweight, and easy to operate. It quickly identifies hot spots through visual surface temperature measurement, accurately locates faults, and facilitates predictive maintenance of equipment. At the price of a point thermometer, you can experience the benefits of a thermal imager. It visualizes defects and offers a wide temperature measurement perspective.

**[Features]**

- **Thermal Imaging Resolution:** 96 × 96, 192 × 192 with ISR function enabled

- **Temperature Measurement Range:** -20°C to 150°C, 100°C to 550°C

- **Supports:** Center point, highest temperature, and lowest temperature measurement

- **Image Storage:** Full-screen temperature information storage, supports offline temperature analysis (with client software)

**[Applications]**

Suitable for distribution cabinet inspection, electrical巡检, automotive repair, and other scenarios.

**Thermal Imaging Field of View: 50°**

**Specifications**

*Specifications*

- **Sensor Type:** Uncooled Vanadium Oxide Microbolometer

- **Detector Resolution:** 96 × 96 (9,216 pixels)

- **Resolution with ISR:** 192 × 192 (36,864 pixels)

- **NETD (Noise Equivalent Temperature Difference):** < 50mK (@ 25°C, F#=1.0)

- **Thermal Imaging Minimum Focus Distance:** 0.1m

- **Field of View:** 50° × 50°

- **Frame Rate:** 25 Hz

- **Minimum Measurement Distance:** 0.1 m

- **Spatial Resolution (IFOV):** 8.89 mrad

- **Thermal Imaging Lens Focal Length:** 1.35 mm

*Visible Light*

- **Resolution:** 640 × 480

- **Maximum Image Size:** 240 × 240

- **Image Resolution:** 240 × 240

*Image Display*

- **Display:** 2.4-inch LCD (320 × 240)

- **Display Modes:** Fusion, Thermal Imaging, Visible Light

- **Maximum Image Size:** 240 × 240

- **Frame Rate:** 25 Hz

- **Image Format:** JPEG with temperature data, supports offline analysis via client

- **Color Palettes:** White Hot, Black Hot, Iron Red, Rainbow, High Temperature Highlight, Red Hot, Fusion

*System Functions*

- **Laser Pointer:** Supported

- **UVC Projection:** Supported

- **Photo Capture:** Supported

- **Text Annotation:** Not Supported

- **Wi-Fi:** Not Supported

- **Storage:** 4 GB built-in eMMC

- **Storage Expansion:** Not Supported

- **Hardware Interface:** Type-C

- **Charging Time:** <3 hours @ 25°C

- **Battery Life:** >8 hours @ 25°C

- **Bluetooth:** Not Supported

- **Illumination:** Not Supported

- **Image Format:** JPEG with temperature data, supports offline analysis via client

- **Focusing Method:** Fixed Focus

*General Specifications*

- **Mounting:** Tripod mount UNC ¼”-20

- **Operating Temperature and Humidity:** -10°C to 50°C, ≤95%

- **Storage Temperature and Humidity:** -40°C to 70°C, ≤95%

- **Protection Rating:** IP54

- **Drop Resistance:** 2 m

*System Parameters*

- **Weight:** 290 g

- **Dimensions:** 196 × 117 × 59 mm

- **Electromagnetic Compatibility (EMC):** GB/T17799.2, GB 17799.3-2012

- **Shock/Vibration:** GB/T 2423.5-2019, GB/T 2423.10-2008

- **Package Contents:** USB cable x1, wrist strap x1, calibration certificate

- **Temperature Measurement Range:** -20°C to 550°C

*Temperature Measurement and Analysis*

- **Temperature Measurement Accuracy:** ±2°C or ±2% of reading (whichever is greater)

- **Safety:** IEC61010

- **Number of Image Files:** 30,000

*Data Storage*

- **Image File Format:** JPEG with temperature data, supports offline analysis via client

- **Hardware Interface:** Type-C

*Client Software*

- **PC Software:** Analyzer

- **App:** Not Supported

- **Projection:** Supported

**Field of View:** 50° × 50°, easily covers target objects.
