Specification Classification: 8 channels, 16 channels, 24 channels, 32 channels, 48 channels, 64 channels Color: Grayish white Material: Aluminum alloy chassis Packaging Specifications: Thermocouples, power cords, instruction manuals, certificates of conformity, and packaged in cartons Parameters Overview of TWC-2C Multi-channel Temperature Tester: ◆ Equipped with a 7-inch true color liquid crystal touch screen. One interface can display the temperature test data of 16 channels and the temperature rise curve simultaneously. ◆ Instrument measurement accuracy: ±0.3% of the reading (rdg) + 1℃. Resolution: 0.1℃. Measurement range: -50 ～1000 ℃. ◆ The instrument is standardly equipped with an RS232 serial port and can communicate serially with a computer. ◆ Content of the testing software: Collect and store temperature data and draw temperature curves. ◆ Equipped with a miniature printer to print multi-channel temperature data regularly. The printing time interval can be set by the user. ◆ The upper and lower limit alarm function is optional. ◆ Configure 2-meter-long original imported American K-type thermocouples for each channel. (It can identify K, T, J, and E-type thermocouples). (The temperature measurement range is -50～260℃, and the wire diameter is 0.522mm); ◆ Equipped with a USB storage function. An 8G USB flash drive is provided, and data can be stored in real time and exported through the software. ◆ The temperature probe can be operated while live (within 250V) without damaging the instrument itself. ◆ Usage environment: Operating temperature: 0 — 40℃, Humidity: 60%±30%; ◆ Power supply: AC220V±10%, 50Hz/60Hz. The power consumption of the whole machine is < 15W. ◆ Appearance dimensions: 330mm (width) × 346mm (length) × 170mm (height)
