400-816-6687RXQC-2C Automotive Wiring Harness Thermal Cycling Temperature Rise Test Bench This testing instrument is developed in accordance with the test methods for the current and temperature rise of electronic connectors such as GB2099, GB7251, GB11022, GB11918, GB13140, GB14048, GB15092, GB15287, GB15288, GB16915, GB17465, GB20234.1, UL310, UL498, UL817, UL941, UL1059, IEC60309, IEC60998, IEC60669, IEC61058, IEC60439, EIA-364-70, and other relevant standards for electrical accessories. It is applicable to the temperature rise tests of products such as grounding resistance tests, appliance switches, plugs and sockets, switchgear, busbars, etc. It has the characteristics of simple operation, accuracy and reliability, and is widely used in manufacturers, quality inspection and scientific research departments. It can also be used to assess the surface heating condition of electrical accessories when connected to a load current, and whether the temperature rise of the electrodes meets the requirements of the standards. 1. Test Current Source: Current program control Maximum Output Voltage: DC5V Output Voltage Display Accuracy: ±(0.2% of the reading + 5 digits) Output Constant and Adjustable Test Current: 2 levels, adjustable from DC 0～20.000～200.00A Current Display Accuracy: ±(0.5% of the reading + 5 digits) Test Current Stability: ±(1% of the set value + 5 digits), response time 1S Output Power Limit: Not exceeding 1KVA 2. Controller: Power-on/Power-off Time: 1～99.99 minutes/hour Number of On-off Cycles: 1～9999 times, with power-off memory function, and it will automatically stop when the set number of cycles is reached 3. Temperature Rise Test: Temperature Measurement Range: 0～260℃, accuracy ±0.3% of the reading + 1℃; Resolution: 0.1℃ 4. Dimensions: Approximately 800mm (width) × 800mm (depth) × 1800mm (height), weighing about 200kg
RXQC-2C Automotive Wiring Harness Thermal Cycling Temperature Rise Test Bench This testing instrument is developed in accordance with the test methods for the current and temperature rise of electronic connectors such as GB2099, GB7251, GB11022, GB11918, GB13140, GB14048, GB15092, GB15287, GB15288, GB16915, GB17465, GB20234.1, UL310, UL498, UL817, UL941, UL1059, IEC60309, IEC60998, IEC60669, IEC61058, IEC60439, EIA-364-70, and other relevant standards for electrical accessories. It is applicable to the temperature rise tests of products such as grounding resistance tests, appliance switches, plugs and sockets, switchgear, busbars, etc. It has the characteristics of simple operation, accuracy and reliability, and is widely used in manufacturers, quality inspection and scientific research departments. It can also be used to assess the surface heating condition of electrical accessories when connected to a load current, and whether the temperature rise of the electrodes meets the requirements of the standards. 1. Test Current Source: Current program control Maximum Output Voltage: DC5V Output Voltage Display Accuracy: ±(0.2% of the reading + 5 digits) Output Constant and Adjustable Test Current: 2 levels, adjustable from DC 0～20.000～200.00A Current Display Accuracy: ±(0.5% of the reading + 5 digits) Test Current Stability: ±(1% of the set value + 5 digits), response time 1S Output Power Limit: Not exceeding 1KVA 2. Controller: Power-on/Power-off Time: 1～99.99 minutes/hour Number of On-off Cycles: 1～9999 times, with power-off memory function, and it will automatically stop when the set number of cycles is reached 3. Temperature Rise Test: Temperature Measurement Range: 0～260℃, accuracy ±0.3% of the reading + 1℃; Resolution: 0.1℃ 4. Dimensions: Approximately 800mm (width) × 800mm (depth) × 1800mm (height), weighing about 200kg
Zhipinhui after-sales service
Equipment after-sales policy:
*Equipment warranty period: One Year
*After sales hotline: 4008166687
1. Our company has assembled a team of experienced on-site engineers and senior technicians who can respond promptly to any equipment issues and provide after-sales maintenance.
2. Within one week of the delivery of the new product, our after-sales technical department staff will provide installation and after-sales training for the equipment at the customer's location based on the contact information and address provided by the customer.
3. All complaints related to product quality will be responded to within 1 hour. Within 3-5 hours within the province and 24-48 hours outside the province, the customer will arrive at the scene and determine the handling measures based on the complaint situation, and carry out after-sales maintenance.
4. To better address customers' difficulties and concerns, our company promises that all maintenance personnel will be on call.
5. Any costs related to product quality during the shelf life will be borne by our company.
6. During the warranty period, we will provide free repairs due to improper use by your side or natural environment. The materials and accessories used for repairs will only be charged at cost price.
