RX9900-WS electric iron temperature testing equipment

1. Overview:

RX9900-WS electric iron temperature test equipment, hereinafter referred to as the test bench, is designed according to the technical requirements of customers. It is suitable for testing the withstand voltage and power of electric irons under normal operation, as well as the temperature test of the bottom plate. The test bench adopts PC+ software program control. The software can set parameters for the test items (optional peak temperature, valley temperature, average temperature control mode, and the upper and lower limit temperatures of the control mode can also be set, and the upper and lower limits of over-temperature, upper and lower limits of temperature difference, and number of operations can be set) to facilitate users to analyze and inspect the product.

2. Main technical indicators

1. Variable frequency voltage-stabilized power supply or adjustable voltage power supply (provided by the user)

Input power supply: AC220V, 50Hz

Output voltage: 0~250V adjustable

Frequency 50Hz, 60Hz, 47~63Hz adjustable

Load stability: 1%

Approximate size: 800*800*1800mm

1.1 Number of test benches: 2; power of each product does not exceed 3000W

1.2 Two silver point temperature probes (both with spring tooling) are installed at each station to test the temperature of the center point and front end of the bottom of the electric iron

1.3 The product cannot be scratched during the test;

2. Temperature measurement range: Temperature measurement range: 0~260℃, resolution 0·1℃
