400-816-6687RX9290 compressor built-in protector test bench
1. Equipment Overview
Equipment use: Applicable to the action temperature, reset temperature and minimum action current of built-in protectors of various specifications of compressors | ||
Workstations: 5 | ||
Specific parameters and requirements | Basic functional requirements | 1. Power supply: 220v50Hz, power less than 4000W |
2. Temperature range: 0℃～140℃ | ||
3. Temperature control accuracy: ±0.2%; | ||
4. Temperature uniformity ≤ 0.2℃ | ||
5. Current value measurement range, 0-30A | ||
6. Medium: high temperature silicone oil (0-250℃), the test machine contains the rated amount of silicone oil, and an additional amount of silicone oil of the same specification is required for backup. (Silicone oil is an insulating medium) | ||
7. Minimum operating current value: During the measurement process, it should have an automatic function. After setting the test parameters such as working temperature, holding time, initial current, adjustment current, and holding time (the current in each stage can be set to the required time), it can automatically time and adjust the current according to the set requirements until the protector is activated, and record the current current when the protector is activated; | ||
8. Working environment: 5-45℃ / 25%-85%RH | ||
RX9290 compressor built-in protector test bench
1. Equipment Overview
Equipment use: Applicable to the action temperature, reset temperature and minimum action current of built-in protectors of various specifications of compressors | ||
Workstations: 5 | ||
Specific parameters and requirements | Basic functional requirements | 1. Power supply: 220v50Hz, power less than 4000W |
2. Temperature range: 0℃～140℃ | ||
3. Temperature control accuracy: ±0.2%; | ||
4. Temperature uniformity ≤ 0.2℃ | ||
5. Current value measurement range, 0-30A | ||
6. Medium: high temperature silicone oil (0-250℃), the test machine contains the rated amount of silicone oil, and an additional amount of silicone oil of the same specification is required for backup. (Silicone oil is an insulating medium) | ||
7.
Minimum operating current value: During the measurement process, it
should have an automatic function. After setting the test parameters
such as working temperature, holding time, initial current, adjustment
current, and holding time (the current in each stage can be set to the
required time), it can automatically time and adjust the current
according to the set requirements until the protector is activated, and
record the current current when the protector is activated; | ||
8. Working environment: 5-45℃ / 25%-85%RH | ||
