400-816-6687RX9900-1QM Electric Hot Pot Airtight Testing Platform
1. Overview
This equipment is specially used for sealing performance testing of household appliances, and tests the overall sealing performance of the whole machine after assembly during the production process. The equipment has one station, which is controlled by PLC and touch screen. It can read out parameters such as pressure value, pressure holding time, leakage volume in real time. After the test is completed, there will be a prompt to show whether it is qualified or not.
2. Main performance parameters
1. Number of stations: 1 station
2. Adjustable cycle: 1S~999S
3. Adjustable pressure holding time: 1s-999s
4. Detection pressure range: 25-35KPa, inflation time 2S, pressure holding time 3S
5. Maximum test pressure: 50KPa. According to product characteristics, the leakage within 5 seconds after stabilization is no more than 5KPA.
6. Air source: 0.8MPa clean compressed air source
7. Power supply for pneumatic electric control valve at workstation: AC220V
8. Indicator light: Alarm buzzer - buzzer for unqualified items
9. The program can be freely upgraded and compiled, which is convenient for use and maintenance
10. Power supply: 220VAC 50Hz 0.5KW, the equipment has the function of power on and off
11. Working environment temperature 25℃±10℃. Relative humidity: 45%~95% RH
III. Test process:
Put the product in the designated position of the airtight tooling, press the start button with both hands, the cylinder moves downward, the equipment moves, and observe the pressure difference indication and machine prompt after maintaining pressure for 3S. After OK, enter the next process.
If it is unqualified, the unqualified red light will be on (indicating that there are defective products at this station) and the alarm buzzer will sound. The operator will take out the defective products and put them in the corresponding defective product box.
RX9900-1QM Electric Hot Pot Airtight Testing Platform
1. Overview
This
equipment is specially used for sealing performance testing of
household appliances, and tests the overall sealing performance of the
whole machine after assembly during the production process. The
equipment has one station, which is controlled by PLC and touch screen.
It can read out parameters such as pressure value, pressure holding
time, leakage volume in real time. After the test is completed, there
will be a prompt to show whether it is qualified or not.
2. Main performance parameters
1. Number of stations: 1 station
2. Adjustable cycle: 1S~999S
3. Adjustable pressure holding time: 1s-999s
4. Detection pressure range: 25-35KPa, inflation time 2S, pressure holding time 3S
5.
Maximum test pressure: 50KPa. According to product characteristics, the
leakage within 5 seconds after stabilization is no more than 5KPA.
6. Air source: 0.8MPa clean compressed air source
7. Power supply for pneumatic electric control valve at workstation: AC220V
8. Indicator light: Alarm buzzer - buzzer for unqualified items
9. The program can be freely upgraded and compiled, which is convenient for use and maintenance
10. Power supply: 220VAC 50Hz 0.5KW, the equipment has the function of power on and off
11. Working environment temperature 25℃±10℃. Relative humidity: 45%~95% RH
III. Test process:
Put
the product in the designated position of the airtight tooling, press
the start button with both hands, the cylinder moves downward, the
equipment moves, and observe the pressure difference indication and
machine prompt after maintaining pressure for 3S. After OK, enter the
next process.
If it is unqualified, the unqualified red light
will be on (indicating that there are defective products at this
station) and the alarm buzzer will sound. The operator will take out the
defective products and put them in the corresponding defective product
box.
Zhipinhui after-sales service
Equipment after-sales policy:
*Equipment warranty period: One Year
*After sales hotline: 4008166687
1. Our company has assembled a team of experienced on-site engineers and senior technicians who can respond promptly to any equipment issues and provide after-sales maintenance.
2. Within one week of the delivery of the new product, our after-sales technical department staff will provide installation and after-sales training for the equipment at the customer's location based on the contact information and address provided by the customer.
3. All complaints related to product quality will be responded to within 1 hour. Within 3-5 hours within the province and 24-48 hours outside the province, the customer will arrive at the scene and determine the handling measures based on the complaint situation, and carry out after-sales maintenance.
4. To better address customers' difficulties and concerns, our company promises that all maintenance personnel will be on call.
5. Any costs related to product quality during the shelf life will be borne by our company.
6. During the warranty period, we will provide free repairs due to improper use by your side or natural environment. The materials and accessories used for repairs will only be charged at cost price.
