400-816-66871. Overview
This system consists of an electrical control cabinet, a test mechanism, etc., making the measurement more scientific and the operation simpler. The control cabinet is equipped with a human-machine interface for control, which is the core of the interaction between the entire control system and the operator. The control core is Japan Mitsubishi's PLC, making the entire system simpler and the control more intuitive and reliable.
2. Related parameters
1. Test object: washing machine water level sensor
2. Power supply: AC220V 50HZ
There is no corrosive or explosive gas indoors.
Working environment temperature: 0-45 degrees, relative humidity: 45%-95% RH
3. Number of workstations: 10 (all 10 workstations can be used for life test, and one workstation can be used for performance test)
4. Control mode: PC + software program control
5. Programmable test parameters:
Test pressure: 0-1000pa adjustable
Test number setting range: 0-999999 times
6. Software function: Start pressure can be set
End pressure can be set
Speed can be set (pressurization speed)
1. Overview
This
system consists of an electrical control cabinet, a test mechanism,
etc., making the measurement more scientific and the operation simpler.
The control cabinet is equipped with a human-machine interface for
control, which is the core of the interaction between the entire control
system and the operator. The control core is Japan Mitsubishi's PLC,
making the entire system simpler and the control more intuitive and
reliable.
2. Related parameters
1. Test object: washing machine water level sensor
2. Power supply: AC220V 50HZ
There is no corrosive or explosive gas indoors.
Working environment temperature: 0-45 degrees, relative humidity: 45%-95% RH
3.
Number of workstations: 10 (all 10 workstations can be used for life
test, and one workstation can be used for performance test)
4. Control mode: PC + software program control
5. Programmable test parameters:
Test pressure: 0-1000pa adjustable
Test number setting range: 0-999999 times
6. Software function: Start pressure can be set
End pressure can be set
Speed can be set (pressurization speed)
Zhipinhui after-sales service
Equipment after-sales policy:
*Equipment warranty period: One Year
*After sales hotline: 4008166687
1. Our company has assembled a team of experienced on-site engineers and senior technicians who can respond promptly to any equipment issues and provide after-sales maintenance.
2. Within one week of the delivery of the new product, our after-sales technical department staff will provide installation and after-sales training for the equipment at the customer's location based on the contact information and address provided by the customer.
3. All complaints related to product quality will be responded to within 1 hour. Within 3-5 hours within the province and 24-48 hours outside the province, the customer will arrive at the scene and determine the handling measures based on the complaint situation, and carry out after-sales maintenance.
4. To better address customers' difficulties and concerns, our company promises that all maintenance personnel will be on call.
5. Any costs related to product quality during the shelf life will be borne by our company.
6. During the warranty period, we will provide free repairs due to improper use by your side or natural environment. The materials and accessories used for repairs will only be charged at cost price.
