400-816-6687ZH-TPH26-7QF/W Professional Handheld Thermal Imager for Temperature Measurement Thermal imaging fixed-focus lens: 6.9mm Minimum focusing distance: 0.1m Resolution: 256×192 high-sensitivity detector 3.5-inch touch sunlight-readable screen Supports the highest temperature, the lowest temperature, and center positioning Supports point, line, and frame temperature measurement Temperature measurement range: -20-150°C or 100-550°C Temperature measurement accuracy: ±2°C or ±2% of the reading (taking the maximum value) Supports 3D noise reduction function, digital zoom, pseudo-color adjustment, and contrast adjustment Supports the fusion of thermal imaging and visible light In cooperation with the app, it supports remote album access, download, and quick report generation Supports Weiying Thermal Vision APP, Analyzer, and UVC screen projection software Specifications and Parameters · Model Sensor type: Uncooled detector Response band: 7.5~14μm NETD (Noise Equivalent Temperature Difference): < 50mk (@25°C, F# = 1.0) Maximum image size: 256×192 Focal length of the thermal imaging lens: 6.9mm Minimum imaging distance: 0.1m · Thermal imaging Field of view: 25°×18.8° Digital zoom: 1.0~8.0 continuous digital zoom Frame rate: 25Hz F value: F1.0 Minimum measurement distance: 0.1m Temperature measurement range: -20°C~550°C Accuracy: ±2°C or ±2%, taking the maximum value Spatial resolution: 1.74mrad (IFOV) Focus mode: Fixed focus, manually adjustable · Visible light Maximum image size: 3264×2448 (8MP) Picture resolution: 3264×2448 Video resolution: 1600×1200 · Image display Display: 3.5'' LCD capacitive touch screen, 640×480 Image mode: Supports 7 pseudo-color modes including white hot, black hot, rainbow, iron red, red hot, fusion, and rain. It also supports two-stage pseudo-color functions such as high-temperature focusing. Function Picture display mode: Visible light, thermal imaging, dual-light fusion, picture-in-picture · System functions Bluetooth: Supported Laser indication: Supported Photographing: Thermal imaging, visible light, dual-light fusion, picture-in-picture Video recording: Thermal imaging, visible light, dual-light fusion, picture-in-picture Illumination: Supported Text annotation: Supported Voice annotation: Supported (60s) Interface language: Chinese WIFI: Supported Storage: 16G (maximum support 128G) Hardware interface: Type-C Battery type: Lithium-ion battery Battery working time: 6h, can be replaced on-site, rechargeable · System parameters Operating temperature and humidity: -10°C ~50°C, ≤95% Protection level: IP54 Drop resistance level: 2m Weight: 660g Dimensions: 244mm×100mm×104mm Accessories: Batteries (2), lanyard, charger, SD card, USB cable, desktop charger adapter, high-strength impact-resistant portable case
ZH-TPH26-7QF/W Professional Handheld Thermal Imager for Temperature Measurement Thermal imaging fixed-focus lens: 6.9mm Minimum focusing distance: 0.1m Resolution: 256×192 high-sensitivity detector 3.5-inch touch sunlight-readable screen Supports the highest temperature, the lowest temperature, and center positioning Supports point, line, and frame temperature measurement Temperature measurement range: -20-150°C or 100-550°C Temperature measurement accuracy: ±2°C or ±2% of the reading (taking the maximum value) Supports 3D noise reduction function, digital zoom, pseudo-color adjustment, and contrast adjustment Supports the fusion of thermal imaging and visible light In cooperation with the app, it supports remote album access, download, and quick report generation Supports Weiying Thermal Vision APP, Analyzer, and UVC screen projection software Specifications and Parameters · Model Sensor type: Uncooled detector Response band: 7.5~14μm NETD (Noise Equivalent Temperature Difference): < 50mk (@25°C, F# = 1.0) Maximum image size: 256×192 Focal length of the thermal imaging lens: 6.9mm Minimum imaging distance: 0.1m · Thermal imaging Field of view: 25°×18.8° Digital zoom: 1.0~8.0 continuous digital zoom Frame rate: 25Hz F value: F1.0 Minimum measurement distance: 0.1m Temperature measurement range: -20°C~550°C Accuracy: ±2°C or ±2%, taking the maximum value Spatial resolution: 1.74mrad (IFOV) Focus mode: Fixed focus, manually adjustable · Visible light Maximum image size: 3264×2448 (8MP) Picture resolution: 3264×2448 Video resolution: 1600×1200 · Image display Display: 3.5'' LCD capacitive touch screen, 640×480 Image mode: Supports 7 pseudo-color modes including white hot, black hot, rainbow, iron red, red hot, fusion, and rain. It also supports two-stage pseudo-color functions such as high-temperature focusing. Function Picture display mode: Visible light, thermal imaging, dual-light fusion, picture-in-picture · System functions Bluetooth: Supported Laser indication: Supported Photographing: Thermal imaging, visible light, dual-light fusion, picture-in-picture Video recording: Thermal imaging, visible light, dual-light fusion, picture-in-picture Illumination: Supported Text annotation: Supported Voice annotation: Supported (60s) Interface language: Chinese WIFI: Supported Storage: 16G (maximum support 128G) Hardware interface: Type-C Battery type: Lithium-ion battery Battery working time: 6h, can be replaced on-site, rechargeable · System parameters Operating temperature and humidity: -10°C ~50°C, ≤95% Protection level: IP54 Drop resistance level: 2m Weight: 660g Dimensions: 244mm×100mm×104mm Accessories: Batteries (2), lanyard, charger, SD card, USB cable, desktop charger adapter, high-strength impact-resistant portable case
Zhipinhui after-sales service
Equipment after-sales policy:
*Equipment warranty period: One Year
*After sales hotline: 4008166687
1. Our company has assembled a team of experienced on-site engineers and senior technicians who can respond promptly to any equipment issues and provide after-sales maintenance.
2. Within one week of the delivery of the new product, our after-sales technical department staff will provide installation and after-sales training for the equipment at the customer's location based on the contact information and address provided by the customer.
3. All complaints related to product quality will be responded to within 1 hour. Within 3-5 hours within the province and 24-48 hours outside the province, the customer will arrive at the scene and determine the handling measures based on the complaint situation, and carry out after-sales maintenance.
4. To better address customers' difficulties and concerns, our company promises that all maintenance personnel will be on call.
5. Any costs related to product quality during the shelf life will be borne by our company.
6. During the warranty period, we will provide free repairs due to improper use by your side or natural environment. The materials and accessories used for repairs will only be charged at cost price.
