400-816-6687ZH-TPH16-6VF/W Handheld Thermal Imaging Thermometer for Temperature Measurement The Zhipinhui TPH16 handheld thermal imaging thermometer for temperature measurement is powerful, easy to use, and highly cost-effective. It can accurately measure the temperature of high-temperature targets in the environment, helping on-site personnel quickly troubleshoot problems, assisting in decision-making, and ensuring safety. It is an ideal tool for fields with temperature measurement requirements such as construction, electrical engineering, and machinery. The device is equipped with a 3.5” touchscreen and has a wifi connection function. It is equipped with a 160 × 120 infrared detector and an 8-megapixel visible light detector, which can simultaneously display the dual-light fusion image of visible light and thermal imaging, helping you discover hidden problems and enabling you to make key decisions more quickly. Technical Parameters *Thermal Imaging Sensor type: Uncooled detector Maximum image size: 160 × 120 Response band: 8~14 μm NETD (Noise Equivalent Temperature Difference): < 50 mk (@25 °C, F#=1.0) Focal length of the thermal imaging lens: 6.2 mm Field of view: 25° × 19° Aperture: F1.1 Digital zoom: 1×, 2×, 4× Frame rate: 25 Hz *Visible Light Maximum image size: 3264 × 2448 Picture resolution: 1600 × 1200 Video resolution: 1600 × 1200 *Image Display Display: 3.5” LCD capacitive touchscreen, 640 × 480 Image modes: Supports 7 pseudo-color modes such as rainbow and iron red Picture display modes: Visible light, thermal imaging, dual-light fusion, picture-in-picture *Functions Temperature measurement range: -20 °C~400 °C Temperature measurement accuracy: ±2 °C or ±2%, whichever is greater Laser indication: Supported Storage capacity: 16 G Photography: Thermal imaging, visible light, dual-light fusion, picture-in-picture Video recording: Thermal imaging, visible light, dual-light fusion, picture-in-picture Lighting: Supported WIFI: Supported Text annotation: Supported Voice annotation: Supported (60 S) Interface language: Chinese *Battery Battery type: Lithium-ion battery Battery working time: 5h, can be replaced on-site, rechargeable Hardware interface: TYPE-C Operating temperature: -10 °C~50 °C Protection level: IP54 Drop resistance level: 2 m Volume: 244 mm × 100 mm × 104 mm Weight: 660 g Accessories: SD card, lanyard, user manual, type-c cable, adapter, safety box
ZH-TPH16-6VF/W Handheld Thermal Imaging Thermometer for Temperature Measurement The Zhipinhui TPH16 handheld thermal imaging thermometer for temperature measurement is powerful, easy to use, and highly cost-effective. It can accurately measure the temperature of high-temperature targets in the environment, helping on-site personnel quickly troubleshoot problems, assisting in decision-making, and ensuring safety. It is an ideal tool for fields with temperature measurement requirements such as construction, electrical engineering, and machinery. The device is equipped with a 3.5” touchscreen and has a wifi connection function. It is equipped with a 160 × 120 infrared detector and an 8-megapixel visible light detector, which can simultaneously display the dual-light fusion image of visible light and thermal imaging, helping you discover hidden problems and enabling you to make key decisions more quickly. Technical Parameters *Thermal Imaging Sensor type: Uncooled detector Maximum image size: 160 × 120 Response band: 8~14 μm NETD (Noise Equivalent Temperature Difference): < 50 mk (@25 °C, F#=1.0) Focal length of the thermal imaging lens: 6.2 mm Field of view: 25° × 19° Aperture: F1.1 Digital zoom: 1×, 2×, 4× Frame rate: 25 Hz *Visible Light Maximum image size: 3264 × 2448 Picture resolution: 1600 × 1200 Video resolution: 1600 × 1200 *Image Display Display: 3.5” LCD capacitive touchscreen, 640 × 480 Image modes: Supports 7 pseudo-color modes such as rainbow and iron red Picture display modes: Visible light, thermal imaging, dual-light fusion, picture-in-picture *Functions Temperature measurement range: -20 °C~400 °C Temperature measurement accuracy: ±2 °C or ±2%, whichever is greater Laser indication: Supported Storage capacity: 16 G Photography: Thermal imaging, visible light, dual-light fusion, picture-in-picture Video recording: Thermal imaging, visible light, dual-light fusion, picture-in-picture Lighting: Supported WIFI: Supported Text annotation: Supported Voice annotation: Supported (60 S) Interface language: Chinese *Battery Battery type: Lithium-ion battery Battery working time: 5h, can be replaced on-site, rechargeable Hardware interface: TYPE-C Operating temperature: -10 °C~50 °C Protection level: IP54 Drop resistance level: 2 m Volume: 244 mm × 100 mm × 104 mm Weight: 660 g Accessories: SD card, lanyard, user manual, type-c cable, adapter, safety box
Zhipinhui after-sales service
Equipment after-sales policy:
*Equipment warranty period: One Year
*After sales hotline: 4008166687
1. Our company has assembled a team of experienced on-site engineers and senior technicians who can respond promptly to any equipment issues and provide after-sales maintenance.
2. Within one week of the delivery of the new product, our after-sales technical department staff will provide installation and after-sales training for the equipment at the customer's location based on the contact information and address provided by the customer.
3. All complaints related to product quality will be responded to within 1 hour. Within 3-5 hours within the province and 24-48 hours outside the province, the customer will arrive at the scene and determine the handling measures based on the complaint situation, and carry out after-sales maintenance.
4. To better address customers' difficulties and concerns, our company promises that all maintenance personnel will be on call.
5. Any costs related to product quality during the shelf life will be borne by our company.
6. During the warranty period, we will provide free repairs due to improper use by your side or natural environment. The materials and accessories used for repairs will only be charged at cost price.
