ZH-TJP10-3AMF手机测温热像仪
·热成像图像:
原始分辨率160 × 120,高灵敏度氧化钒非制冷探测器
支持定时、温差快门校正
支持3D降噪功能,图像细节增强功能
支持15种伪彩可调节
·测温功能:
测温范围:-20 °C~350 °C
测温精度:±2 °C或±2%
规格参数
·热成像
传感器类型 非制冷氧化钒微幅射热计
探测器分辨率 160 × 120
响应波段 8~14 μm
NETD(噪声等效温差) <50 mk(@25 °C,F#=1.0)
最大图像尺寸 160 × 120
最小成像距离 0.2 m
视场角 38.3° × 50°
帧频 25 Hz
像元尺寸 17 μm
最小测量距离 20 cm
F值 F1.1
测温单位 摄氏度、华氏度、开尔文
测温范围 -20 °C~350 °C
精度 ±2 °C或± 2%
空间分辨率(IFOV) 5.31mrad
·系统功能
电源接口 TYPE-C
·系统参数
工作温度和湿度 0 °C~40 °C
存储温度和湿度 -20 °C~60 °C
防护等级 IP40
防摔等级 1 m
重量 26 g
尺寸 54.1 mm × 15 mm × 27.5 mm
配件 布包、说明文档
ZH-TJP10-3AMF手机测温热像仪
·热成像图像:
原始分辨率160 × 120,高灵敏度氧化钒非制冷探测器
支持定时、温差快门校正
支持3D降噪功能,图像细节增强功能
支持15种伪彩可调节
·测温功能:
测温范围:-20 °C~350 °C
测温精度:±2 °C或±2%
规格参数
·热成像
传感器类型 非制冷氧化钒微幅射热计
探测器分辨率 160 × 120
响应波段 8~14 μm
NETD(噪声等效温差) <50 mk(@25 °C,F#=1.0)
最大图像尺寸 160 × 120
最小成像距离 0.2 m
视场角 38.3° × 50°
帧频 25 Hz
像元尺寸 17 μm
最小测量距离 20 cm
F值 F1.1
测温单位 摄氏度、华氏度、开尔文
测温范围 -20 °C~350 °C
精度 ±2 °C或± 2%
空间分辨率(IFOV) 5.31mrad
·系统功能
电源接口 TYPE-C
·系统参数
工作温度和湿度 0 °C~40 °C
存储温度和湿度 -20 °C~60 °C
防护等级 IP40
防摔等级 1 m
重量 26 g
尺寸 54.1 mm × 15 mm × 27.5 mm
配件 布包、说明文档
