400-816-6687ZH-TPH10-3AUF Handheld Thermal Imaging Thermometer for Temperature Measurement *Thermal Imaging Image: l Original resolution: 160 × 120, with a high-sensitivity vanadium oxide uncooled detector l Supports timed temperature difference shutter correction l Supports 3D noise reduction function and image detail enhancement function l Supports the adjustment of 4 pseudo-color modes *Temperature Abnormality Alarm Function: l Supports temperature measurement at the central point, maximum temperature, and minimum temperature l Temperature measurement range: -20 °C~350 °C l Temperature measurement accuracy: ±2 °C (or 2% of the measurement range), whichever is greater Technical Parameters *Thermal Imaging Detector type: Uncooled vanadium oxide microbolometer Detector resolution: 160 × 120 Response band: 8~14 μm Pixel size: 17 um NETD (Noise Equivalent Temperature Difference): < 50 mk (@25 °C, F#=1.0) Focal length of the thermal imaging lens: f3.1 fixed focus and athermalized Minimum measurement distance: 15 cm Field of view: 38.3° × 50° Aperture: F1.1 *Temperature Measurement Temperature measurement rules: 3 temperature measurement points (central point, maximum temperature, minimum temperature) Accuracy: ±2 °C or ±2% (whichever is greater) Temperature measurement range: -20 °C~350 °C Temperature measurement units: Celsius, Fahrenheit, Kelvin Maximum image size: 160 × 120 Frame rate: 25 Hz *Image Display Display: 2.4-inch LCD screen (320 × 240) Image modes: White hot, black hot, iron red, rainbow Image format: JPEG image with temperature measurement information, supports offline analysis by the client Laser indicator: The laser indicates the temperature measurement area and is activated by the trigger button Storage: 8 GB Micro SD card Storage expansion: Supports up to 128 G at maximum *System Functions Power interface: Micro USB direct charging Battery type: Rechargeable lithium-ion battery Charging time: <3H @25 °C Battery working time: >8H @25 °C Power management: Adjustable; off, 5 minutes, 10 minutes, 20 minutes *Battery Operating temperature: -10 °C~50 °C Humidity: ≤95% Storage temperature: -40 °C~70 °C Drop resistance: 2 m Protection level: IP54 Dimensions: 196 mm × 78 mm × 59 mm Weight: <350 g (including battery) Accessories: 5 V power adapter, USB cable, wrist strap lanyard, 8GB Micro SD card, instruction document *Recommended power supply model: The included 5 V power adapter + micro USB cable.
ZH-TPH10-3AUF Handheld Thermal Imaging Thermometer for Temperature Measurement *Thermal Imaging Image: l Original resolution: 160 × 120, with a high-sensitivity vanadium oxide uncooled detector l Supports timed temperature difference shutter correction l Supports 3D noise reduction function and image detail enhancement function l Supports the adjustment of 4 pseudo-color modes *Temperature Abnormality Alarm Function: l Supports temperature measurement at the central point, maximum temperature, and minimum temperature l Temperature measurement range: -20 °C~350 °C l Temperature measurement accuracy: ±2 °C (or 2% of the measurement range), whichever is greater Technical Parameters *Thermal Imaging Detector type: Uncooled vanadium oxide microbolometer Detector resolution: 160 × 120 Response band: 8~14 μm Pixel size: 17 um NETD (Noise Equivalent Temperature Difference): < 50 mk (@25 °C, F#=1.0) Focal length of the thermal imaging lens: f3.1 fixed focus and athermalized Minimum measurement distance: 15 cm Field of view: 38.3° × 50° Aperture: F1.1 *Temperature Measurement Temperature measurement rules: 3 temperature measurement points (central point, maximum temperature, minimum temperature) Accuracy: ±2 °C or ±2% (whichever is greater) Temperature measurement range: -20 °C~350 °C Temperature measurement units: Celsius, Fahrenheit, Kelvin Maximum image size: 160 × 120 Frame rate: 25 Hz *Image Display Display: 2.4-inch LCD screen (320 × 240) Image modes: White hot, black hot, iron red, rainbow Image format: JPEG image with temperature measurement information, supports offline analysis by the client Laser indicator: The laser indicates the temperature measurement area and is activated by the trigger button Storage: 8 GB Micro SD card Storage expansion: Supports up to 128 G at maximum *System Functions Power interface: Micro USB direct charging Battery type: Rechargeable lithium-ion battery Charging time: <3H @25 °C Battery working time: >8H @25 °C Power management: Adjustable; off, 5 minutes, 10 minutes, 20 minutes *Battery Operating temperature: -10 °C~50 °C Humidity: ≤95% Storage temperature: -40 °C~70 °C Drop resistance: 2 m Protection level: IP54 Dimensions: 196 mm × 78 mm × 59 mm Weight: <350 g (including battery) Accessories: 5 V power adapter, USB cable, wrist strap lanyard, 8GB Micro SD card, instruction document *Recommended power supply model: The included 5 V power adapter + micro USB cable.
Zhipinhui After-Sales Policy:
*After-Sales Hotline: +864008166687
1. Our company has assembled a team of experienced field engineers and senior technicians to promptly respond
to any equipment issues and provide after-sales maintenance.
2. Within China, within one week of new product delivery, our after-sales technical staff will install the equipment and
provide after-sales training at the customer's location, using the contact information and address provided by the customer.
3. All complaints related to product quality will be responded to within one hour. Within 3-5 hours within the province,
and within 24-48 hours outside the province, we will arrive at the customer's site,
determine the appropriate action based on the complaint, and provide after-sales repairs. (Domestic)
4. For international travel, our company can also arrange for an after-sales engineer to visit you for installation and
commissioning. Please discuss any travel and catering issues in advance.
We also provide video installation guides for you to choose from, providing you with a comprehensive and multi-faceted solution.
5. Any material costs related to product quality during the warranty period will be borne by our company.
6. During the warranty period, we will provide free repairs due to improper use or environmental factors.
The materials and accessories used for repairs will be charged at cost only.
