400-816-6687ZH-TJP24-7RF-P20Max Mobile Phone Thermal Imaging Thermometer Thermal Imaging Image: ● Original resolution of 256 × 192, with a high-sensitivity vanadium oxide uncooled detector ● Supports timed and temperature difference shutter correction ● Supports 3D noise reduction function and image detail enhancement function ● Supports the adjustment of 15 pseudo-color modes ● One-click AGC function to locate the target ● Minimum focusing distance of 10 cm, enabling clear close-range detection Temperature Measurement Function: ● Temperature measurement range: -20°C ~ 350°C ● Temperature measurement accuracy: ±2°C or ±2% ● Temperature measurement rules: Supports the configuration of 3 custom points and 3 custom boxes, and also supports the configuration of emissivity and distance ● Used in conjunction with the Weiying Thermal Vision APP, with a Type-C interface Specification Parameters *Thermal Imaging Sensor type: Uncooled vanadium oxide microbolometer Detector resolution: 256×192 Response band: 7.5~14 μm NETD (Noise Equivalent Temperature Difference): < 50 mk (@25 °C, F#=1.0) Focal length of the thermal imaging lens: 6.9mm Minimum imaging distance: 0.1m Field of view: 25°× 18.8° Frame rate: 25 Hz Pixel size: 12 um F-number: F1.0 Temperature measurement units: Celsius, Fahrenheit, Kelvin Temperature measurement range: -20 °C ~ 350 °C Accuracy: ±2 °C or ±2% Spatial resolution (IFOV): 1.74 mrad *System Function Power interface: Type-C *System Parameters Power consumption: 350mW Operating temperature and humidity: -10 °C~50 °C Storage temperature and humidity: -20 °C ~60 °C Protection level: IP40 Weight: 24g Dimensions: 26.6mm × 26.6mm × 25mm Accessories: Cloth bag, instruction document, extension cable *Client Software App: Weiying Thermal Vision
ZH-TJP24-7RF-P20Max Mobile Phone Thermal Imaging Thermometer Thermal Imaging Image: ● Original resolution of 256 × 192, with a high-sensitivity vanadium oxide uncooled detector ● Supports timed and temperature difference shutter correction ● Supports 3D noise reduction function and image detail enhancement function ● Supports the adjustment of 15 pseudo-color modes ● One-click AGC function to locate the target ● Minimum focusing distance of 10 cm, enabling clear close-range detection Temperature Measurement Function: ● Temperature measurement range: -20°C ~ 350°C ● Temperature measurement accuracy: ±2°C or ±2% ● Temperature measurement rules: Supports the configuration of 3 custom points and 3 custom boxes, and also supports the configuration of emissivity and distance ● Used in conjunction with the Weiying Thermal Vision APP, with a Type-C interface Specification Parameters *Thermal Imaging Sensor type: Uncooled vanadium oxide microbolometer Detector resolution: 256×192 Response band: 7.5~14 μm NETD (Noise Equivalent Temperature Difference): < 50 mk (@25 °C, F#=1.0) Focal length of the thermal imaging lens: 6.9mm Minimum imaging distance: 0.1m Field of view: 25°× 18.8° Frame rate: 25 Hz Pixel size: 12 um F-number: F1.0 Temperature measurement units: Celsius, Fahrenheit, Kelvin Temperature measurement range: -20 °C ~ 350 °C Accuracy: ±2 °C or ±2% Spatial resolution (IFOV): 1.74 mrad *System Function Power interface: Type-C *System Parameters Power consumption: 350mW Operating temperature and humidity: -10 °C~50 °C Storage temperature and humidity: -20 °C ~60 °C Protection level: IP40 Weight: 24g Dimensions: 26.6mm × 26.6mm × 25mm Accessories: Cloth bag, instruction document, extension cable *Client Software App: Weiying Thermal Vision
Zhipinhui after-sales service
Equipment after-sales policy:
*Equipment warranty period: One Year
*After sales hotline: 4008166687
1. Our company has assembled a team of experienced on-site engineers and senior technicians who can respond promptly to any equipment issues and provide after-sales maintenance.
2. Within one week of the delivery of the new product, our after-sales technical department staff will provide installation and after-sales training for the equipment at the customer's location based on the contact information and address provided by the customer.
3. All complaints related to product quality will be responded to within 1 hour. Within 3-5 hours within the province and 24-48 hours outside the province, the customer will arrive at the scene and determine the handling measures based on the complaint situation, and carry out after-sales maintenance.
4. To better address customers' difficulties and concerns, our company promises that all maintenance personnel will be on call.
5. Any costs related to product quality during the shelf life will be borne by our company.
6. During the warranty period, we will provide free repairs due to improper use by your side or natural environment. The materials and accessories used for repairs will only be charged at cost price.
