ET35 series precision digital bridge (LCR)

-Parameter Introduction-

The ET35 series LCR digital bridge is a high-precision component parameter analyzer designed using the principle of an automatic balancing bridge. Its 10Hz~1MHz test bandwidth, continuously adjustable frequency, 0.05% basic measurement accuracy, and the automatic level control function, list scanning and file counting functions provided by the instrument provide accurate and complete measurement and analysis for most components and materials. It is widely used in product research and development, component factory inspection, product online sorting and other applications.

Product features:

v 0.05% basic accuracy;

v Measurement speed up to 200 times/second;

v 10Hz-1MHz frequency measurement range, continuously adjustable, 1mHz continuous step adjustable;

v Excitation signal amplitude 10mV-2000mV adjustable, 1mV continuous step adjustable;

v Internal programmable DC bias voltage -2V ~ +2V;

v Support external DC bias voltage -60V ~ +60V;

v Support external current source;

v Automatic level adjustment of voltage or current;

v V, I and other test signal monitoring function;

v 10-point list scan test function;

v 10-level sorting and counting function;

v 100 sets of self-defined frequency point calibration data;

v 7-inch LCD display, Chinese and English interface, with bridge operating system;

v Standard interfaces: USB, Ethernet, RS232, GPIB, HANDLER interface;


ET35 series precision digital bridge (LCR)

-Parameter Introduction-

Product features:

v 0.05% basic accuracy;

v Measurement speed up to 200 times/second;

v 10Hz-1MHz frequency measurement range, continuously adjustable, 1mHz continuous step adjustable;

v Excitation signal amplitude 10mV-2000mV adjustable, 1mV continuous step adjustable;

v Internal programmable DC bias voltage -2V ~ +2V;

v Support external DC bias voltage -60V ~ +60V;

v Support external current source;

v Automatic level adjustment of voltage or current;

v V, I and other test signal monitoring function;

v 10-point list scan test function;

v 10-level sorting and counting function;

v 100 sets of self-defined frequency point calibration data;

v 7-inch LCD display, Chinese and English interface, with bridge operating system;

v Standard interfaces: USB, Ethernet, RS232, GPIB, HANDLER interface;
