ET45 series desktop bridge-Parameter Introduction-
Product Description:
The ET45 series LCR digital bridge is a component parameter analyzer designed based on the principle of automatic balancing bridge. Its 10Hz~100kHz test bandwidth, continuously adjustable frequency, 0.1% basic measurement accuracy and the file classification function provided by the instrument provide accurate and complete measurement and analysis for most components and materials. It is widely used in product research and development, component factory inspection, product online sorting and other applications.
Product features:
Ø Measurement frequency up to 100kHz, 1Hz step continuously adjustable
Ø Test level 10~2000mV, 1mV step continuously adjustable
Ø Basic measurement accuracy 0.1%
Ø Support DC resistance (DCR), electrolytic capacitance measurement
Ø Internal bias voltage output 0mV~1500mV
Ø 3.5-inch TFT display, 5-digit display
Ø Communication interface: USB Device, RS232, Handle;
Ø Data recording function (maximum value, minimum value, average value)
Ø Support SCPI communication protocol
Ø Provide system settings, which can be configured in Chinese or English, buzzer, screen brightness, etc. as needed
Ø Automatic or locked range
Ø With open circuit and short circuit calibration function
Ø Comparator selection (5 gears), alarm function
Ø 7-point list scan
ET45 series desktop bridge-Parameter Introduction-
Product Description:
The ET45 series LCR digital bridge is a component parameter analyzer designed based on the principle of automatic balancing bridge. Its 10Hz~100kHz test bandwidth, continuously adjustable frequency, 0.1% basic measurement accuracy and the file classification function provided by the instrument provide accurate and complete measurement and analysis for most components and materials. It is widely used in product research and development, component factory inspection, product online sorting and other applications.
Product features:
Ø Measurement frequency up to 100kHz, 1Hz step continuously adjustable
Ø Test level 10~2000mV, 1mV step continuously adjustable
Ø Basic measurement accuracy 0.1%
Ø Support DC resistance (DCR), electrolytic capacitance measurement
Ø Internal bias voltage output 0mV~1500mV
Ø 3.5-inch TFT display, 5-digit display
Ø Communication interface: USB Device, RS232, Handle;
Ø Data recording function (maximum value, minimum value, average value)
Ø Support SCPI communication protocol
Ø Provide system settings, which can be configured in Chinese or English, buzzer, screen brightness, etc. as needed
Ø Automatic or locked range
Ø With open circuit and short circuit calibration function
Ø Comparator selection (5 gears), alarm function
Ø 7-point list scan
