ET44 series desktop bridge

Non-standard products

Delivery

Free delivery

reservation

400-816-6687

Product Details Parameter Overview evaluate（0） After sales guarantee

Book Now

ET44 series desktop bridge- Parameter Introduction

Product Description:

The ET44 series LCR digital bridge is a component parameter analyzer designed using the principle of an automatic balancing bridge. Its 10Hz~100kHz test bandwidth, 0.1% basic measurement accuracy, and the file classification function provided by the instrument provide accurate and complete measurement and analysis for most components and materials. It is widely used in product research and development, component factory inspection, product online sorting and other applications.

Product features:

Ø Measurement frequency up to 100kHz;

Ø Test level 100~2000mV

Ø Support DC resistance (DCR), electrolytic capacitance measurement

Ø Internal bias voltage output 0mV~1500mV

Ø 3.5-inch TFT LCD display, 5-digit display

Ø Communication: USB Device, RS232, Handle

Ø Data recording function (maximum value, minimum value, average value)

Ø Support SCPI communication protocol

Ø Provide system settings, which can be configured as Chinese or English, buzzer, screen brightness, etc. as needed

Ø Basic measurement accuracy 0.1%

Ø Automatic and manual range

Ø With open circuit and short circuit calibration function

Ø Comparator selection (5 gears), alarm function

Ø 7-point list scan

General technical specifications:

l Power supply voltage: 220V.AC±10%, or 110V.AC±10%, 45~65Hz;

l Power consumption: <10W;

l Display: 3.5-inch TFT LCD screen, resolution 480×320, 16M colors;

l Temperature range: 10℃~+40℃ in operating state, -10℃~+60℃ in non-operating state;

l Humidity range: 0~40℃, ≤90% relative humidity;

l Interface: RS232, USB Device, Handle as standard;

l Weight: 2.1kg;
