400-816-6687RX1810 Glow Wire Tester The glow wire tester of our company has an outer case made of all stainless steel plates with high-grade spray painting. It is controlled by an imported Mitsubishi PLC microcomputer, achieving a fully intelligent control mode. It is equipped with a seven-inch TFT true-color touch screen from Weinview in Taiwan. It can realize the upgrade of the user-friendly operation interface for customers and truly achieve international comparison results. The glow wire tester is used for simulating test items in accordance with the programs of ignition sources without flames as specified in standards such as GB 4706.1, GB 7000.1, IEC60695-2-10～IEC60695-2-13 "Glow Wire/Hot Wire, Basic Test Methods, Glow Wire Test Apparatus and General Test Procedures", UL 746A, IEC829, DIN695, VDE0471, etc. The glow wire tester is applicable to the research, production, and quality inspection departments of electrical and electronic products and their components, such as lighting equipment, low-voltage electrical appliances, household appliances, machine tool electrical appliances, motors, electric tools, electronic instruments, electrical measuring instruments, information technology equipment, electrical office equipment, electrical connection parts and auxiliary parts. It is also applicable to the industries of insulating materials, engineering plastics, or other solid combustible materials. Technical Parameters:
Control mode | It is controlled by an imported Mitsubishi PLC, achieving a fully intelligent control mode, and the system is stable. |
Display mode | It is equipped with a liquid crystal display from Weinview in Taiwan, which can realize the upgrade of the user-friendly operation interface for customers. |
Glow wire | A special standard ring-shaped one with a thickness of 4mm ± 0.04mm, made of Ni/Cr(77/20), and it is horizontally placed in a static state. |
Thermocouple | Type K with a diameter of Φ1.0mm, imported insulated high-temperature resistant armored thermocouple. The armored sheath can withstand heat up to 1100 ℃ (superior to the standard of 1050 ℃). |
The heating temperature of the glow wire when it is powered on | 500 ℃ to 1000 ℃ (pre-settable), with a temperature fluctuation of less than 2 ℃. |
The pressure of the test sample during the glow wire test | 0.95N±0.1 |
Maximum penetration depth | 7mm ± 0.5mm (adjustable, with fully automatic positioning) |
The moving speed of the test sample | 10mm /s ～ 25mm /s (fully automatic) |
Test time | 30s ± 0.1s (pre-settable from 1s to 999.9s) |
The thickness of the ignition base plate | A white pine wood board with a thickness of 10mm is covered with standard tissue paper of 12g/m² to 30g/m², and it is placed 200mm ± 5mm below the glow wire. |
The volume of the test area | The volume of the background is ≥ 0.5m³, the color of the background is black, and the illuminance of the background is ≤ 20Lx. |
External dimensions | Width: 1120mm × Depth: 520mm × Height: 1020mm, and the exhaust hole has a diameter of 100mm. |
Power supply power | 1kVA 220V 50- |
Zhipinhui after-sales service
Equipment after-sales policy:
*Equipment warranty period: One Year
*After sales hotline: 4008166687
1. Our company has assembled a team of experienced on-site engineers and senior technicians who can respond promptly to any equipment issues and provide after-sales maintenance.
2. Within one week of the delivery of the new product, our after-sales technical department staff will provide installation and after-sales training for the equipment at the customer's location based on the contact information and address provided by the customer.
3. All complaints related to product quality will be responded to within 1 hour. Within 3-5 hours within the province and 24-48 hours outside the province, the customer will arrive at the scene and determine the handling measures based on the complaint situation, and carry out after-sales maintenance.
4. To better address customers' difficulties and concerns, our company promises that all maintenance personnel will be on call.
5. Any costs related to product quality during the shelf life will be borne by our company.
6. During the warranty period, we will provide free repairs due to improper use by your side or natural environment. The materials and accessories used for repairs will only be charged at cost price.
