400-816-6687ZH8870 Thermocouple Life Test Stand
1. Product Introduction:
Thermocouple
life test bench meets the technical requirements specified in CJ 30-
-2013 "Flame-out protection device for thermoelectric fuel appliances",
"Household gas stoves (GB16410-2007)" and "General test methods for
household gas appliances (GB16411-2008)". It is suitable for the quality
inspection department of the production enterprise to conduct
performance testing and random inspection of products. The action
mechanism of the test bench adopts pneumatic devices, and the
straight-moving cylinder realizes the entire process of the thermocouple
working in the flame of the set temperature and leaving the flame. The
test circuit adopts a microcomputer data acquisition system, and the
flexible human-machine interface software adjustment function greatly
facilitates the user's operation.
2. Test function:
2.1. Design station: 1-5
2.2. Heating range: 500℃～800℃ (adjustable)
2.3. Heating method: liquefied gas combustion flame heating
2.4. Temperature control accuracy: ±20℃ (under reference conditions)
2.5. Control method: computer human-machine interface
2.6. Thermoelectric potential measurement range: 0～50mV
2.7. Measurement accuracy: 0.1mV
2.8. Cold and hot characteristic working time: 0～9999s (adjustable)
2.9. Time measurement resolution: 0.1s
ZH8870 Thermocouple Life Test Stand
1. Product Introduction:
Thermocouple life test bench meets the technical requirements specified in CJ 30- -2013 "Flame-out protection device for thermoelectric fuel appliances", "Household gas stoves (GB16410-2007)" and "General test methods for household gas appliances (GB16411-2008)". It is suitable for the quality inspection department of the production enterprise to conduct performance testing and random inspection of products. The action mechanism of the test bench adopts pneumatic devices, and the straight-moving cylinder realizes the entire process of the thermocouple working in the flame of the set temperature and leaving the flame. The test circuit adopts a microcomputer data acquisition system, and the flexible human-machine interface software adjustment function greatly facilitates the user's operation.
2. Test function:
2.1. Design station: 1-5
2.2. Heating range: 500℃～800℃ (adjustable)
2.3. Heating method: liquefied gas combustion flame heating
2.4. Temperature control accuracy: ±20℃ (under reference conditions)
2.5. Control method: computer human-machine interface
2.6. Thermoelectric potential measurement range: 0～50mV
2.7. Measurement accuracy: 0.1mV
2.8. Cold and hot characteristic working time: 0～9999s (adjustable)
2.9. Time measurement resolution: 0.1s
