ZH8818 Gas Water Heater Comprehensive Testing System
1. Overview:
Comprehensive
test system for gas water heaters. This gas instantaneous water heater
performance test bench is developed according to GB 6932-2007 "Household
gas instantaneous water heaters" standard, using imported and domestic
advanced devices and testing technologies. It is mainly used for testing
the performance of gas instantaneous water heaters below 30kW
(adjustable according to user requirements), as well as thermal
efficiency and heat load. The test bench adopts PLC master control, and
uses microcomputer technology to transmit test parameters and control
signals between the computer and the test system. The computer system is
the core of control and recording, and can perform test automation
control through a friendly and flexible human-machine interface. Various
calculation formula software are integrated, original records are
stored, and query management is convenient, and test reports are
automatically generated.
2. Technical parameters:
●Number of workstations: 1
●Inlet water temperature: 0～100.0℃, precision: 0.5 level
●Outlet water temperature: 0～100.0℃, precision: 0.5 level
●Gas temperature: 0～50.0℃, precision: 0.5 level
●Inlet water high pressure: 0.0～1.6Mpa adjustable, precision: 0.5 level
●Inlet water low pressure: 0.0～0.6Mpa adjustable, precision: 0.5 level
●Gas primary pressure: 0～5000Pa, precision: 0.5 level
●Gas secondary pressure: 0～5000Pa, precision: 0.5 level
●Water flow: 0～30L/min adjustable, precision: 0.5 level
●Gas flow: 5L～80L/min, precision: 0.5 level
●Exhaust temperature: 0-300℃, accuracy: 0.5 level
III. Functional configuration:
●
Thermal efficiency/heat load/hot water yield test: All formulas are
integrated, temperature, pressure, and flow are tested by high-precision
sensors, and the data are displayed on the computer. The test results
are automatically calculated, and the computer human-machine interface
is used for intelligent operation
● Hot water temperature rise
● Water stop temperature rise
● Heating time
● Hot water temperature stabilization time
● Start water flow
● Shutdown water flow
● Water temperature overshoot amplitude
● Display accuracy
● Water system pressure resistance: The pressure can reach more than 1.6Mpa and work stably;
● Smoke exhaust temperature
●
The water flow of the test bench can be adjusted, and the water flow
can be adjusted according to product requirements during the test;
● Gas pressure: 1500~3500 pa adjustable
● Electrical parameter test: voltage, current and power during operation; working voltage 0-300V adjustable
● The test bench has a power-off memory function
●
The chassis adopts an aluminum profile frame combined with a stainless
steel plate, The pipeline uses stainless steel pipes combined with
copper pipes, and the pipeline is beautiful and elegant
●All test
data automatically generates test reports, and the report can be
printed by connecting to a printer, and historical data can be queried
ZH8818 Gas Water Heater Comprehensive Testing System
1. Overview:
Comprehensive test system for gas water heaters. This gas instantaneous water heater performance test bench is developed according to GB 6932-2007 "Household gas instantaneous water heaters" standard, using imported and domestic advanced devices and testing technologies. It is mainly used for testing the performance of gas instantaneous water heaters below 30kW (adjustable according to user requirements), as well as thermal efficiency and heat load. The test bench adopts PLC master control, and uses microcomputer technology to transmit test parameters and control signals between the computer and the test system. The computer system is the core of control and recording, and can perform test automation control through a friendly and flexible human-machine interface. Various calculation formula software are integrated, original records are stored, and query management is convenient, and test reports are automatically generated.
2. Technical parameters:
●Number of workstations: 1
●Inlet water temperature: 0～100.0℃, precision: 0.5 level
●Outlet water temperature: 0～100.0℃, precision: 0.5 level
●Gas temperature: 0～50.0℃, precision: 0.5 level
●Inlet water high pressure: 0.0～1.6Mpa adjustable, precision: 0.5 level
●Inlet water low pressure: 0.0～0.6Mpa adjustable, precision: 0.5 level
●Gas primary pressure: 0～5000Pa, precision: 0.5 level
●Gas secondary pressure: 0～5000Pa, precision: 0.5 level
●Water flow: 0～30L/min adjustable, precision: 0.5 level
●Gas flow: 5L～80L/min, precision: 0.5 level
●Exhaust temperature: 0-300℃, accuracy: 0.5 level
III. Functional configuration:
● Thermal efficiency/heat load/hot water yield test: All formulas are integrated, temperature, pressure, and flow are tested by high-precision sensors, and the data are displayed on the computer. The test results are automatically calculated, and the computer human-machine interface is used for intelligent operation
● Hot water temperature rise
● Water stop temperature rise
● Heating time
● Hot water temperature stabilization time
● Start water flow
● Shutdown water flow
● Water temperature overshoot amplitude
● Display accuracy
● Water system pressure resistance: The pressure can reach more than 1.6Mpa and work stably;
● Smoke exhaust temperature
● The water flow of the test bench can be adjusted, and the water flow can be adjusted according to product requirements during the test;
● Gas pressure: 1500~3500 pa adjustable
● Electrical parameter test: voltage, current and power during operation; working voltage 0-300V adjustable
● The test bench has a power-off memory function
● The chassis adopts an aluminum profile frame combined with a stainless steel plate, The pipeline uses stainless steel pipes combined with copper pipes, and the pipeline is beautiful and elegant
●All test data automatically generates test reports, and the report can be printed by connecting to a printer, and historical data can be queried
