ZH8814 Gas Water Heater Durability Test Stand

1. Overview:

The durability test bench for gas water heaters is used to perform durability tests on gas water heaters in accordance with relevant standards and customer requirements. The test bench can be controlled by ordinary control or touch screen, or by industrial control computers; it is suitable for testing all gas water heaters; the chassis is made of aluminum profile frame and stainless steel sheet metal, and has a beautiful appearance;

2. Technical parameters:

2.1. Water pressure test: 0. 05MPa~0.50MPa;

2.2. Gas pressure test: 2kPa~4kPa; adjustable

2.3. Waterway on-off time can be set between 0~999s

2.4. The number of tests can be preset between 0~999999 times;

2.5. Design test stations: 1-5.

2.6. It has a compressed air connection port and a water blowing device to dry the water in the water heater after the test;

2.7. It has the function of testing the primary pressure and water pressure of the gas system;

2.8. The hook of the water heater can be moved up and down and left and right;

2.9. It has a beautiful appearance, a compact and reasonable structure, and various components and measuring instruments are easy to disassemble and install;

2.10. The water pressure and gas pressure tests use pointer instruments, which are convenient and intuitive;

2.11. The number of tests has a power-off memory function.
