Technical specifications:
Power supply voltage: 220V.AC±10%, 110V.AC±10%, 45~65Hz
Display: 3.5-inch TFT LCD, resolution 480×320, 16M colors
Operating temperature: 0° to 40°, storage temperature: -10° to 50°, relative humidity: <80%
Dimensions: 265×105×305mm (width×height×depth),
Weight: 2.3kg

Basic features:

* 3.5-inch TFT LCD screen display (resolution 320*480), screen brightness adjustable
* Chinese and English language switching
* Dual parameter display, can display two parameters of the same input signal (for example, AC voltage value and AC frequency value can be displayed simultaneously under AC voltage measurement)
* Adjustable reading rate, fast, medium and slow;
* AC and DC voltage, AC and DC current, 2-wire/4-wire resistance measurement
* DC current maximum 10A, DC voltage maximum 1000V
* Period and frequency measurement, maximum frequency value 20MHz
* Capacitance measurement, maximum value 10mF
* True RMS AC voltage and AC current measurement, bandwidth up to 100kHz
* Provide automatic and single trigger measurement mode
* With AC+DC measurement
* Manual or automatic range can be selected
* With duty cycle measurement function
* Setting function: Chinese and English language, buzzer, screen brightness, etc. can be set
* Various mathematical functions: statistics, maximum and minimum values, limits, T/F, dB, dBm, relative, MX+B
* With external calibration function, supports user self-calibration
* Supports multiple sensors: 10 types of thermocouples, 4 types of thermal resistors
* Supports custom sensors
* With reading hold function
* Supports SCPI protocol, provides programming documentation
* Data memory storage function and read function, convenient for viewing data information
