400-816-6687RX9518 self ballasted light load cabinet
1. Overview
The equipment is designed and manufactured according to the normal test load in Chapter 19.3 of GB16915.1-2014
2. Technical parameters
2.1. Input power: AC 220V, 50/60Hz, 20KVA
2.1.1. Test the external power supply, and the expected short-circuit current (RMS) of the power supply should be between 3kA and 4kA when the power factor is 0.9 (lagging)
2.2. Output voltage: AC0~250V continuously adjustable
2.3. Rated current of the switch under test, not exceeding 20A
2.4. Rated power: 10~500W Continuously adjustable
2.4.1. Adjustable range of series resistance: 0.005~2.00Ω
2.4.2. Adjustable range of capacitance: 1~800uF pulse capacitor
2.4.3. Load switching mode: large-capacity panel switch switching
2.5. 90±5 degrees of load conduction angle voltage waveform
2.6. Oscilloscope waveform of load current peak value in accordance with Article 19.3 of GB 16915.1-2014, and integral waveform of I2t, the waveform can be clearly displayed, and the peak current value can be directly read
2.7. The equipment adopts a color touch screen with a size of not less than 7 inches, the CPU adopts an industrial-grade 32-bit embedded single-chip microcomputer, with an embedded oscilloscope card, and the current waveform can be directly displayed on the screen
2.8. Display accuracy: voltage: ±0.1% reading + 0.1% range
2.8.1 Current: ±0.1% reading + 0.1% range
2.8.2 Power: ±0.1% reading + 0.1% range
2.8.3 Power factor: ±0.03
2.9 Output channels: 1 channel; the device comes with a pre-adjustment function, which is convenient for adjusting the rated parameters before use
2.10 Working cycle: intermittent working system, heat dissipation method is air cooling
2.11 Equipment protection function configuration: leakage protection, overload, overheating protection
2.12 Dimensions: about 900×900×1600 (mm), weighing about 300kg, universal wheels with brakes, easy to move
2.13 Environmental conditions for use:
A. Ambient temperature: 0℃～40℃, indoor type
B. Relative humidity: maximum relative humidity 95% without condensation, no corrosive gas or steam, etc.
C. Altitude does not exceed 1000m
RX9518 self ballasted light load cabinet
1. Overview
The equipment is designed and manufactured according to the normal test load in Chapter 19.3 of GB16915.1-2014
2. Technical parameters
2.1. Input power: AC 220V, 50/60Hz, 20KVA
2.1.1.
Test the external power supply, and the expected short-circuit current
(RMS) of the power supply should be between 3kA and 4kA when the power
factor is 0.9 (lagging)
2.2. Output voltage: AC0~250V continuously adjustable
2.3. Rated current of the switch under test, not exceeding 20A
2.4. Rated power: 10~500W Continuously adjustable
2.4.1. Adjustable range of series resistance: 0.005~2.00Ω
2.4.2. Adjustable range of capacitance: 1~800uF pulse capacitor
2.4.3. Load switching mode: large-capacity panel switch switching
2.5. 90±5 degrees of load conduction angle voltage waveform
2.6.
Oscilloscope waveform of load current peak value in accordance with
Article 19.3 of GB 16915.1-2014, and integral waveform of I2t, the
waveform can be clearly displayed, and the peak current value can be
directly read
2.7. The equipment adopts a color touch screen with
a size of not less than 7 inches, the CPU adopts an industrial-grade
32-bit embedded single-chip microcomputer, with an embedded oscilloscope
card, and the current waveform can be directly displayed on the screen
2.8. Display accuracy: voltage: ±0.1% reading + 0.1% range
2.8.1 Current: ±0.1% reading + 0.1% range
2.8.2 Power: ±0.1% reading + 0.1% range
2.8.3 Power factor: ±0.03
2.9
Output channels: 1 channel; the device comes with a pre-adjustment
function, which is convenient for adjusting the rated parameters before
use
2.10 Working cycle: intermittent working system, heat dissipation method is air cooling
2.11 Equipment protection function configuration: leakage protection, overload, overheating protection
2.12 Dimensions: about 900×900×1600 (mm), weighing about 300kg, universal wheels with brakes, easy to move
2.13 Environmental conditions for use:
A. Ambient temperature: 0℃～40℃, indoor type
B. Relative humidity: maximum relative humidity 95% without condensation, no corrosive gas or steam, etc.
C. Altitude does not exceed 1000m
