RX9528 Contact Performance Testing System
1. Overview:
This series of relay contact performance test system (hereinafter
referred to as test equipment) is designed according to GB14536.11,
GB14598.1-2001, GB7261-2008 "Basic Test Methods for Relay Protection and
Safety Automatic Devices", IEC60255-1 and other relevant requirements.
2. Main technical parameters of the equipment:
2.1. Relay sample coil working voltage:
DC voltage regulation: DC3~50V adjustable Display accuracy: ±1% reading ±2 digits
AC: AC0～ 250V adjustable, display accuracy: ±1% reading ±2 characters
2.2, Test station: 1 station
2.3, Load working mode: AC/DC resistive load, AC inductive load, DC inductive load selectable
2.4, AC test:
Test voltage: AC0～ 250V, input by external adjustable regulated power supply (provided by the customer, power 10KW)
Test current: 0.2～ 10A adjustable
Power factor 0.3～ 1 adjustable
DC test:
Test voltage: DC10～ 250V adjustable, external adjustable regulated power supply input (provided by the customer, power 10KW)
On-off current: 1～ 30A adjustable, time 200mS
Off current: 0.2～ 10A adjustable
L/R time constant: 0～ 40mS adjustable
RX9528 Contact Performance Testing System
1. Overview: This series of relay contact performance test system (hereinafter referred to as test equipment) is designed according to GB14536.11, GB14598.1-2001, GB7261-2008 "Basic Test Methods for Relay Protection and Safety Automatic Devices", IEC60255-1 and other relevant requirements.
2. Main technical parameters of the equipment:
2.1. Relay sample coil working voltage:
DC voltage regulation: DC3~50V adjustable Display accuracy: ±1% reading ±2 digits
AC: AC0～ 250V adjustable, display accuracy: ±1% reading ±2 characters
2.2, Test station: 1 station
2.3, Load working mode: AC/DC resistive load, AC inductive load, DC inductive load selectable
2.4, AC test:
Test voltage: AC0～ 250V, input by external adjustable regulated power supply (provided by the customer, power 10KW)
Test current: 0.2～ 10A adjustable
Power factor 0.3～ 1 adjustable
DC test:
Test voltage: DC10～ 250V adjustable, external adjustable regulated power supply input (provided by the customer, power 10KW)
On-off current: 1～ 30A adjustable, time 200mS
Off current: 0.2～ 10A adjustable
L/R time constant: 0～ 40mS adjustable
