RX9516 capacitor load control cabinet
1. Overview
A
matching device designed according to the relevant provisions of
UL1054, UL 61058 RC Load and GB15092.1 for capacitive load disconnection
and normal operation of related electrical accessories.
2. Technical parameters:
2.1. Equipment input power: AC220V 50Hz
2.2. Test voltage: AC 125 / 250V (optional) Display accuracy 1%FS
2.3. Rated current: 1-16A (optional) Display accuracy 1%
2.4. Set according to standard requirements >110V, surge factor X=16, <110V, surge factor X=10
2.5.
Test current is divided into the following levels: Rated/surge: 2/32A,
4/64A, 6/96A, 8/128A, 10/160A, 12/192A, 16/256A, etc. (optional)
2.6. The external switch to be tested should be controlled by an external mechanism. Its on time: 2S; off time: >15s
2.7. According to Article 17 of GB15092.1
2.8. The capacitor can be cut off to become a pure resistance load
2.9. The test current waveform is displayed by the user's own oscilloscope for observation
RX9516 capacitor load control cabinet
1. Overview
A matching device designed according to the relevant provisions of UL1054, UL 61058 RC Load and GB15092.1 for capacitive load disconnection and normal operation of related electrical accessories.
2. Technical parameters:
2.1. Equipment input power: AC220V 50Hz
2.2. Test voltage: AC 125 / 250V (optional) Display accuracy 1%FS
2.3. Rated current: 1-16A (optional) Display accuracy 1%
2.4. Set according to standard requirements >110V, surge factor X=16, <110V, surge factor X=10
2.5. Test current is divided into the following levels: Rated/surge: 2/32A, 4/64A, 6/96A, 8/128A, 10/160A, 12/192A, 16/256A, etc. (optional)
2.6. The external switch to be tested should be controlled by an external mechanism. Its on time: 2S; off time: >15s
2.7. According to Article 17 of GB15092.1
2.8. The capacitor can be cut off to become a pure resistance load
2.9. The test current waveform is displayed by the user's own oscilloscope for observation
