The EVWBT series bidirectional dual-channel DC test power supply has
the characteristics of bidirectional energy flow. It can not only
provide power to the load, but also feed back power to the power grid
without pollution, saving space and cost for users.
It has two
independent DC outputs, and the voltage, current and other parameters of
the two outputs can be set separately. It is particularly suitable for
energy feedback drag test benches and can adapt to motor controllers
with two different voltage levels. It supports voltage 24~800V (1000V),
current 0~1000A (peak 1300A)/power 0~500KW (peak 650KW) and is
continuously adjustable within the full range.
1. Adopting four-quadrant control technology, energy flows
bidirectionally within full power, stable and reliable operation, energy
saving and high efficiency.
2. It has multiple output modes of constant voltage, constant current and constant power.
3. Rapid transient response.
4. Adopting high-speed digital control technology, the output accuracy reaches 0.1%.
5.
Adopting PWM rectification technology, the power factor is >0.99,
the input harmonic is <3%, and the efficiency is greater than 93%.
6. It has automatic voltage drop compensation function, which automatically compensates for line voltage drop.
7. Adopting seven-inch touch screen operation, convenient operation and display.
8.
The output parameters and protection parameters are programmable, which
can be applied to different types of equipment testing.
9. The internal components adopt international brands such as LEM and Infineon, and the equipment has high reliability.
10. Adopting modular design, the equipment is easy to maintain in the later stage.
The EVWBT series bidirectional dual-channel DC test power supply has the characteristics of bidirectional energy flow. It can not only provide power to the load, but also feed back power to the power grid without pollution, saving space and cost for users.
It has two independent DC outputs, and the voltage, current and other parameters of the two outputs can be set separately. It is particularly suitable for energy feedback drag test benches and can adapt to motor controllers with two different voltage levels. It supports voltage 24~800V (1000V), current 0~1000A (peak 1300A)/power 0~500KW (peak 650KW) and is continuously adjustable within the full range.
1. Adopting four-quadrant control technology, energy flows bidirectionally within full power, stable and reliable operation, energy saving and high efficiency.
2. It has multiple output modes of constant voltage, constant current and constant power.
3. Rapid transient response.
4. Adopting high-speed digital control technology, the output accuracy reaches 0.1%.
5. Adopting PWM rectification technology, the power factor is >0.99, the input harmonic is <3%, and the efficiency is greater than 93%.
6. It has automatic voltage drop compensation function, which automatically compensates for line voltage drop.
7. Adopting seven-inch touch screen operation, convenient operation and display.
8. The output parameters and protection parameters are programmable, which can be applied to different types of equipment testing.
9. The internal components adopt international brands such as LEM and Infineon, and the equipment has high reliability.
10. Adopting modular design, the equipment is easy to maintain in the later stage.
Zhipinhui after-sales service
Equipment after-sales policy:
*Equipment warranty period: One Year
*After sales hotline: 4008166687
1. Our company has assembled a team of experienced on-site engineers and senior technicians who can respond promptly to any equipment issues and provide after-sales maintenance.
2. Within one week of the delivery of the new product, our after-sales technical department staff will provide installation and after-sales training for the equipment at the customer's location based on the contact information and address provided by the customer.
3. All complaints related to product quality will be responded to within 1 hour. Within 3-5 hours within the province and 24-48 hours outside the province, the customer will arrive at the scene and determine the handling measures based on the complaint situation, and carry out after-sales maintenance.
4. To better address customers' difficulties and concerns, our company promises that all maintenance personnel will be on call.
5. Any costs related to product quality during the shelf life will be borne by our company.
6. During the warranty period, we will provide free repairs due to improper use by your side or natural environment. The materials and accessories used for repairs will only be charged at cost price.
