What are the performance characteristics of the air conditioning pipe group flow test bench

　　

该设备主要用于测试和监控空调系统管组的流体传输能力，保证产品在使用过程中的效率与可靠性。那空调管组流量测试台有哪些性能特点，来看广州智品汇电子科技是如何介绍。
This equipment is primarily used to test and monitor the fluid flow capacity of air conditioning system pipes, ensuring product efficiency and reliability during use. What are the performance features of the air conditioning pipe flow test bench? Let's see how Guangzhou Zhipinhui Electronic Technology describes it.

1. Nitrogen Source:

A. Gas supply volume not less than 18 m³/h

B. Gas supply pressure not less than 1.5 MPa

C. Gas source must be external

D. Equipment equipped with a gas storage tank to ensure stable gas supply

E. Equipped with an oil-water separator

2. Pressure Control Device:

A. Pressure Adjustment Range: 0.1-1.0 MPa

B. Pressure Measurement Accuracy: ±2%

C. Digital Display

3. Inspection Station: Single station, left and right switchable

A single station can inspect up to a 1-input, 24-outlet pipe set. Split into two stations, it can inspect two 1-input, 12-outlet pipe sets (left and right program switching)

4. Flow Measurement Range: 0-100 L/min

Flow Measurement Accuracy: ±2%
