What are the performance characteristics of the electronic expansion valve flow test bench

　　

本设备适用于电子膨胀阀、四通阀、其他管件的流量测试，全程PLC+软件监控，采用气体流量计检测测试产品的对应流量。那电子膨胀阀流量测试台有哪些性能特点，来看广州智品汇电子科技怎么介绍。
This device is suitable for flow testing electronic expansion valves, four-way valves, and other pipe fittings. It features full PLC and software monitoring and uses a gas flow meter to detect the flow rate of the test product. What are the performance features of the electronic expansion valve flow test bench? Let's hear what Guangzhou Zhipinhui Electronic Technology has to say about it.

1. Number of Workstations: 1, with 3 branch circuits. You can select any branch for testing.

2. Power Supply: AC 220V 50Hz

3. Test Medium: Air

4. Air Source Pressure: 0.8MPa clean compressed air

5. Flow Meter Performance: Three flow meters are provided, with ranges of 0-50L/min, 0-250L/min, and 0-1000L/min.

6. Pressure Reducing Valve Performance: Imported high-precision electrical proportional pressure regulating valve with a sensitivity of 0.2%F.S. and repeatability within ±0.5%F.S.

7. Test Pressure: 0.1-0.5 MPa compressed air (adjustable)

8. Test Object: Electronic expansion valve

9. Flow Test: Test pressure is 0.1 MPa or 0.5 MPa, valve opening pulse count and frequency are adjustable (configurable), and flow rate range is 0-1000 L/min. Multiple test points can be set (every 100 steps), with a different pulse count set for each point. Flow rates at different openings are sequentially tested, and acceptance is automatically determined based on the upper and lower flow deviations. A flow curve can be plotted.
