ET5420 Dual Channel Programmable DC Electronic Load

Non-standard products
Specification classification
ET5420 dual channel
colour
High-grade matte white
material
High-end integrated chassis
Delivery
Free delivery
400-816-6687
Humanized design:
l Adopt 2.8-inch TFT LCD display screen, rich display content, support Chinese and English display;
l Simple and convenient operation process, with intuitive interface display system, easy to use;
l With key lock function to prevent misoperation;

High-performance load:
l Provide CC, CV, CR, CP and CC+CV, CR+CV basic measurement modes;
l Provide professional battery test and LED test;
l Dynamic test mode, can test the dynamic output performance of power supply;
l Scan test mode, can test the continuity of power supply output within a certain range;
l List mode, can simulate multiple load state changes;
l Short circuit test, used to simulate load short circuit;
l Built-in buzzer alarm;
l Power off to keep data storage function;
l Can be remotely operated through USB interface;

Multiple safety protection:
l With overvoltage, overcurrent, overpower protection function, can flexibly set overvoltage and overcurrent parameters to effectively protect the load;
l It has a secondary over-temperature protection function, realizing dual over-temperature protection of software and hardware;
l It has an intelligent fan speed control function, which effectively reduces the fan noise during operation;
l It has output polarity reverse connection protection;

General technical specifications:
l Power supply voltage: 220V.AC±10%, or 110V.AC±10%, 45-65Hz
l Display: 2.8-inch TFT LCD screen, resolution 400×240
l Operating temperature: 0℃ to 40℃
l Storage temperature: -10℃ to 70℃
l Relative humidity: <80%
l Interface: USB as standard
Dimensions: 90mm×190mm×300mm (width×height×depth)




Humanized design:
l Adopt 2.8-inch TFT LCD display screen, rich display content, support Chinese and English display;
l Simple and convenient operation process, with intuitive interface display system, easy to use;
l With key lock function to prevent misoperation;

High-performance load:
l Provide CC, CV, CR, CP and CC+CV, CR+CV basic measurement modes;
l Provide professional battery test and LED test;
l Dynamic test mode, can test the dynamic output performance of power supply;
l Scan test mode, can test the continuity of power supply output within a certain range;
l List mode, can simulate multiple load state changes;
l Short circuit test, used to simulate load short circuit;
l Built-in buzzer alarm;
l Power off to keep data storage function;
l Can be remotely operated through USB interface;

Multiple safety protection:
l With overvoltage, overcurrent, overpower protection function, can flexibly set overvoltage and overcurrent parameters to effectively protect the load;
l It has a secondary over-temperature protection function, realizing dual over-temperature protection of software and hardware;
l It has an intelligent fan speed control function, which effectively reduces the fan noise during operation;
l It has output polarity reverse connection protection;

General technical specifications:
l Power supply voltage: 220V.AC±10%, or 110V.AC±10%, 45-65Hz
l Display: 2.8-inch TFT LCD screen, resolution 400×240
l Operating temperature: 0℃ to 40℃
l Storage temperature: -10℃ to 70℃
l Relative humidity: <80%
l Interface: USB as standard
Dimensions: 90mm×190mm×300mm (width×height×depth)
