400-816-6687ZH9902 Electronic Expansion Valve Flow Testing Machine (New)
一、Overview
This machine is designed according to JBT-10212 and JBT-10386, and is suitable for testing the flow characteristics, valve opening pulse, valve port leakage, maximum action pressure difference test, reverse valve opening pressure difference and other tests of electronic expansion valves. After setting the parameters through the computer, the test can be started with one key, and the flow characteristics and valve port leakage parameter curves can be generated and the test results can be recorded.
二、Technical indicators
2．1．Power supply: AC220V, 50HZ. Power, about 1KW；
2．2．Gas source: clean high-purity nitrogen above 6Mpa；
2．3．Operating environment: ①Humidity range 38∽85%RH (non-condensing environment)
②Temperature range -10～40℃
③ No strong electric field or magnetic field interference
④Gas source pressure is stable
2．4．Number of workstations: 2
2．5．Test items: ①Internal leakage test
②Flow characteristics test
③Forward maximum valve opening pressure difference test
④Reverse maximum valve opening pressure difference test
2．6．Pressure sensor: accuracy better than ±0.25%
2．7．Digital gas flow meter: accuracy better than ±1%
2．8．Voltage: Accuracy better than ±0.5%
ZH9902 Electronic Expansion Valve Flow Testing Machine (New)
一、Overview
This machine is designed according to JBT-10212 and JBT-10386, and is suitable for testing the flow characteristics, valve opening pulse, valve port leakage, maximum action pressure difference test, reverse valve opening pressure difference and other tests of electronic expansion valves. After setting the parameters through the computer, the test can be started with one key, and the flow characteristics and valve port leakage parameter curves can be generated and the test results can be recorded.
二、Technical indicators
2．1．Power supply: AC220V, 50HZ. Power, about 1KW；
2．2．Gas source: clean high-purity nitrogen above 6Mpa；
2．3．Operating environment: ①Humidity range 38∽85%RH (non-condensing environment)
②Temperature range -10～40℃
③ No strong electric field or magnetic field interference
④Gas source pressure is stable
2．4．Number of workstations: 2
2．5．Test items: ①Internal leakage test
②Flow characteristics test
③Forward maximum valve opening pressure difference test
④Reverse maximum valve opening pressure difference test
2．6．Pressure sensor: accuracy better than ±0.25%
2．7．Digital gas flow meter: accuracy better than ±1%
2．8．Voltage: Accuracy better than ±0.5%
