400-816-6687ZH9932 Copper Tube Air Tightness Water Tester
一、Overview
The high-efficiency pipe air tightness water test bench is a special equipment used for straight high-efficiency pipe air tightness
and water immersion testing.There are 5 workstations for simultaneous testing.
The maximum length of a single pipe does not exceed 7 meters and the diameter does not exceed 30MM.
By adjusting the fixing block and replacing the sealing joints on both sides, it can be applied to the airtight
water immersion test of high-efficiency pipes with different pipe diameters.
二、Technical parameters
2.1、Equipment power: AC220V/50HZ/1Kw.
2.2、Low-pressure air source: ≤0.8Mpa clean compressed air.
2.3、 Medium pressure air source: clean compressed air not less than 4.0Mpa.
2.4、Station cycle: 1 out of 5 (10 pieces/minute, the pressure holding stage is calculated as 15S)
2.5、Gas detection pressure: 0.05-4.0Mpa adjustable, pressure gauge 1.6 level 5 independent.
2.6、Applicable pipe specifications: Φ15.88, Φ19.05, Φ22.23, Φ25.4, Φ28.57,
a total of 5 specifications, each providing 10 sealing heads.
2.7、Applicable tube length: 1000-7000mm
2.8、The holding time can be set: 0-999S
ZH9932 Copper Tube Air Tightness Water Tester
一、Overview
The high-efficiency pipe air tightness water test bench is a special equipment used for straight high-efficiency pipe air tightness
and water immersion testing.There are 5 workstations for simultaneous testing.
The maximum length of a single pipe does not exceed 7 meters and the diameter does not exceed 30MM.
By adjusting the fixing block and replacing the sealing joints on both sides, it can be applied to the airtight
water immersion test of high-efficiency pipes with different pipe diameters.
二、Technical parameters
2.1、Equipment power: AC220V/50HZ/1Kw.
2.2、Low-pressure air source: ≤0.8Mpa clean compressed air.
2.3、 Medium pressure air source: clean compressed air not less than 4.0Mpa.
2.4、Station cycle: 1 out of 5 (10 pieces/minute, the pressure holding stage is calculated as 15S)
2.5、Gas detection pressure: 0.05-4.0Mpa adjustable, pressure gauge 1.6 level 5 independent.
2.6、Applicable pipe specifications: Φ15.88, Φ19.05, Φ22.23, Φ25.4, Φ28.57,
a total of 5 specifications, each providing 10 sealing heads.
2.7、Applicable tube length: 1000-7000mm
2.8、The holding time can be set: 0-999S
Zhipinhui After-Sales Policy:
*After-Sales Hotline: +864008166687
1. Our company has assembled a team of experienced field engineers and senior technicians to promptly respond
to any equipment issues and provide after-sales maintenance.
2. Within China, within one week of new product delivery, our after-sales technical staff will install the equipment and
provide after-sales training at the customer's location, using the contact information and address provided by the customer.
3. All complaints related to product quality will be responded to within one hour. Within 3-5 hours within the province,
and within 24-48 hours outside the province, we will arrive at the customer's site,
determine the appropriate action based on the complaint, and provide after-sales repairs. (Domestic)
4. For international travel, our company can also arrange for an after-sales engineer to visit you for installation and
commissioning. Please discuss any travel and catering issues in advance.
We also provide video installation guides for you to choose from, providing you with a comprehensive and multi-faceted solution.
5. Any material costs related to product quality during the warranty period will be borne by our company.
6. During the warranty period, we will provide free repairs due to improper use or environmental factors.
The materials and accessories used for repairs will be charged at cost only.
