ZH9902 Electronic Expansion Valve Comprehensive Test Equipment
This equipment is designed according to JBT-10212 and JBT-10386. It is suitable for testing the flow characteristics, valve opening pulse, valve leakage, maximum action pressure difference test, reverse valve opening pressure difference, fatigue resistance test and other tests of electronic expansion valves. It adopts imported electronic digital flowmeter with flow test error of ±1%. The pulse number can be set arbitrarily according to the valve opening requirements, and the flow change value of each pulse number can be displayed.The system is automatically controlled, the output test pressure ratio is adjustable, the valve input pulse number can be set, the system pressure, flow parameters and pulse number can be detected in real time, the flow and pressure mutation points can be identified, and the test can be started with one button after the parameters are set by the computer, and the flow characteristics and valve port leakage parameter curves can be generated and the test results can be recorded;
2、Technical indicators
2．1．Power supply: AC220V, 50HZ. Power, about 1KW；
2．2．Gas source: clean high-purity nitrogen or compressed air above 6Mpa；
2．3．Operating environment: ①Humidity range 38∽85%RH (non-condensing environment)
②Temperature range -10～40℃
③ No strong electric field or magnetic field interference
④Gas source pressure is stable
2．4．Number of workstations: 2
2．5．Test items: ①Internal leakage test
②Flow characteristics test
③Forward maximum valve opening pressure difference test
④Reverse maximum valve opening pressure difference test
⑤Fatigue resistance test
2．6．Pressure sensor: accuracy better than ±0.25%
2．7．Digital gas flow meter: accuracy better than ±1%, range 0~500L/min
ZH9902 Electronic Expansion Valve Comprehensive Test Equipment
This equipment is designed according to JBT-10212 and JBT-10386. It is suitable for testing the flow characteristics, valve opening pulse, valve leakage, maximum action pressure difference test, reverse valve opening pressure difference, fatigue resistance test and other tests of electronic expansion valves. It adopts imported electronic digital flowmeter with flow test error of ±1%. The pulse number can be set arbitrarily according to the valve opening requirements, and the flow change value of each pulse number can be displayed.The system is automatically controlled, the output test pressure ratio is adjustable, the valve input pulse number can be set, the system pressure, flow parameters and pulse number can be detected in real time, the flow and pressure mutation points can be identified, and the test can be started with one button after the parameters are set by the computer, and the flow characteristics and valve port leakage parameter curves can be generated and the test results can be recorded;
2、Technical indicators
2．1．Power supply: AC220V, 50HZ. Power, about 1KW；
2．2．Gas source: clean high-purity nitrogen or compressed air above 6Mpa；
2．3．Operating environment: ①Humidity range 38∽85%RH (non-condensing environment)
②Temperature range -10～40℃
③ No strong electric field or magnetic field interference
④Gas source pressure is stable
2．4．Number of workstations: 2
2．5．Test items: ①Internal leakage test
②Flow characteristics test
③Forward maximum valve opening pressure difference test
④Reverse maximum valve opening pressure difference test
⑤Fatigue resistance test
2．6．Pressure sensor: accuracy better than ±0.25%
2．7．Digital gas flow meter: accuracy better than ±1%, range 0~500L/min
Zhipinhui after-sales service
Equipment after-sales policy:
*Equipment warranty period: One Year
*After sales hotline: 4008166687
1. Our company has assembled a team of experienced on-site engineers and senior technicians who can respond promptly to any equipment issues and provide after-sales maintenance.
2. Within one week of the delivery of the new product, our after-sales technical department staff will provide installation and after-sales training for the equipment at the customer's location based on the contact information and address provided by the customer.
3. All complaints related to product quality will be responded to within 1 hour. Within 3-5 hours within the province and 24-48 hours outside the province, the customer will arrive at the scene and determine the handling measures based on the complaint situation, and carry out after-sales maintenance.
4. To better address customers' difficulties and concerns, our company promises that all maintenance personnel will be on call.
5. Any costs related to product quality during the shelf life will be borne by our company.
6. During the warranty period, we will provide free repairs due to improper use by your side or natural environment. The materials and accessories used for repairs will only be charged at cost price.
