RX-CBE9800C Capacitor Durability Tester

Equipment Overview	This device is designed and manufactured in accordance with the requirements of GB/T 6346.14-2015, GB/T3667·1－2016, IEC60252, and Japan JIS C 4908-2007. It is suitable for capacitor manufacturers, household appliance factories, and quality inspection departments to conduct quality inspections on capacitors. The device uses parallel reactors for precise compensation, making it very low in terms of grid capacity. It uses PLC+touch screen control, which can digitally set the test voltage, operating time, test capacity, etc.; and digitally display the test voltage and each capacitor test current. The system is equipped with electric motors, which can automatically increase or decrease the voltage, and at the same time complete the automatic voltage regulation of the output voltage, eliminating the need for a voltage regulator. It has the characteristics of simple operation, intuitive display, and convenient adjustment.
Capacitance range	1～100μF Un ≤ 500V
Workstation	12 workstations, each equipped with an overload short-circuit protection switch
Equipment load capacity	Maximum is no more than 1200uF
Test voltage	AC 0～700V continuously adjustable, Digital display accuracy ±(1% reading + 2 characters) Voltage control accuracy: ±(1% + 2V), voltage setting resolution is 1V
Continuous mode test time	0～9999.9H Power off retention, the capacitor automatically discharges after the test is completed Time control accuracy index: ±(0·1%＋1min;)
Continuity test mode	On-off time: 1~99s, adjustable; Number of tests: 1~999999 times, adjustable Charging resistance is automatically set according to the standard
Current display	Total current: 0～5A Digital display Accuracy ±2％FS
Control Display	Adopt Siemens PLC + touch screen to set parameters, control, and real-time display of test voltage, current, time, number of times and other parameters
Power supply	Single AC 220V 50Hz 4KVA

RX-CBE9800C Capacitor Durability Tester

Equipment Overview	This device is designed and manufactured in accordance with the requirements of GB/T 6346.14-2015, GB/T3667·1－2016, IEC60252, and Japan JIS C 4908-2007. It is suitable for capacitor manufacturers, household appliance factories, and quality inspection departments to conduct quality inspections on capacitors. The device uses parallel reactors for precise compensation, making it very low in terms of grid capacity. It uses PLC+touch screen control, which can digitally set the test voltage, operating time, test capacity, etc.; and digitally display the test voltage and each capacitor test current. The system is equipped with electric motors, which can automatically increase or decrease the voltage, and at the same time complete the automatic voltage regulation of the output voltage, eliminating the need for a voltage regulator. It has the characteristics of simple operation, intuitive display, and convenient adjustment.
Capacitance range	1～100μF Un ≤ 500V
Workstation	12 workstations, each equipped with an overload short-circuit protection switch
Equipment load capacity	Maximum is no more than 1200uF
Test voltage	AC 0～700V continuously adjustable, Digital display accuracy ±(1% reading + 2 characters) Voltage control accuracy: ±(1% + 2V), voltage setting resolution is 1V
Continuous mode test time	0～9999.9H Power off retention, the capacitor automatically discharges after the test is completed Time control accuracy index: ±(0·1%＋1min;)
Continuity test mode	On-off time: 1~99s, adjustable; Number of tests: 1~999999 times, adjustable Charging resistance is automatically set according to the standard
Current display	Total current: 0～5A Digital display Accuracy ±2％FS
Control Display	Adopt Siemens PLC + touch screen to set parameters, control, and real-time display of test voltage, current, time, number of times and other parameters
Power supply	Single AC 220V 50Hz 4KVA
