400-816-6687RX-CBE6800 capacitor destructive testing device
According to the standard | The
latest standards such as GB 3667.1-2016, GB 18489, VDE0560-8, and
IEC60252 require destructive test items for AC motor running capacitors
and AC motor self-healing starting capacitors with a rated voltage of
500V or less. It contains two parts: DC test instrument and AC
instrument. The DC power supply should be able to provide an open
circuit voltage equivalent to 10UN and have the ability to provide a
continuous short-circuit current greater than 50mA; the AC power supply
should be able to provide a test voltage equivalent to 1.3UN, and the
instantaneous short-circuit current should be at least 300A. The
equipment has DC voltage and current, AC voltage and current display;
the equipment also has load short circuit, overload and other protection
measures; it has the characteristics of simple operation, intuitive
display, and convenient adjustment.
|
Control method | The whole machine adopts PLC+touch screen control to automatically control the voltage increase and decrease and complete the test automatically. |
Test scope | Capacity 1～100uF |
Equipment load | 1 self-healing capacitor |
Test voltage | AC: 0~700V ±(0.5% of reading + 0.5% of reading range) |
DC: 0～2500～4000～5000Ｖ ±(0.75% reading + 0.75% reading range) | |
Current display | AC current: 1~25A ±(0.75% of reading + 0.75% of reading range) |
DC current: 1~100mA ±(0.75% of reading + 0.75% of reading range) | |
Device Function | The equipment has electric voltage regulation and automatic timing functions; the equipment has its own power-on preheating function; there are over-current, over-voltage and other protection measures; there is leakage protection, and the test box is safe and explosion-proof to ensure safe and reliable operation of the test. |
Test Selection | The program can set the S1S2 or S3 working mode. The difference lies in the different circuit connections. When the capacitor under test is short-circuited, the cruelty of the test is different. |
Electric heating blast drying oven for test | The inner tank capacity is about 30L |
Equipment power supply | AC220V±10%, capacity 30KVA |
Device size | Length 1600 width 650 height 1600, weight about 500Kg |
RX-CBE6800 capacitor destructive testing device
According to the standard | The latest standards such as GB 3667.1-2016, GB 18489, VDE0560-8, and IEC60252 require destructive test items for AC motor running capacitors and AC motor self-healing starting capacitors with a rated voltage of 500V or less. It contains two parts: DC test instrument and AC instrument. The DC power supply should be able to provide an open circuit voltage equivalent to 10UN and have the ability to provide a continuous short-circuit current greater than 50mA; the AC power supply should be able to provide a test voltage equivalent to 1.3UN, and the instantaneous short-circuit current should be at least 300A. The equipment has DC voltage and current, AC voltage and current display; the equipment also has load short circuit, overload and other protection measures; it has the characteristics of simple operation, intuitive display, and convenient adjustment.
|
Control method | The whole machine adopts PLC+touch screen control to automatically control the voltage increase and decrease and complete the test automatically. |
Test scope | Capacity 1～100uF |
Equipment load | 1 self-healing capacitor |
Test voltage | AC: 0~700V ±(0.5% of reading + 0.5% of reading range) |
DC: 0～2500～4000～5000Ｖ ±(0.75% reading + 0.75% reading range) | |
Current display | AC current: 1~25A ±(0.75% of reading + 0.75% of reading range) |
DC current: 1~100mA ±(0.75% of reading + 0.75% of reading range) | |
Device Function | The equipment has electric voltage regulation and automatic timing functions; the equipment has its own power-on preheating function; there are over-current, over-voltage and other protection measures; there is leakage protection, and the test box is safe and explosion-proof to ensure safe and reliable operation of the test. |
Test Selection | The program can set the S1S2 or S3 working mode. The difference lies in the different circuit connections. When the capacitor under test is short-circuited, the cruelty of the test is different. |
Electric heating blast drying oven for test | The inner tank capacity is about 30L |
Equipment power supply | AC220V±10%, capacity 30KVA |
Device size | Length 1600 width 650 height 1600, weight about 500Kg |
