RX-CBE9850 capacitor pulse voltage test device (new model)

According to the standard	GB_T 6346.14-2015, IEC 384-14: 2005, Clause 4.13, design and manufacture, test the overvoltage performance of capacitors; IEC384-14: 2005, GB/T 14472-1998 Appendix A, Figure A1 and Table A1 requirements;
Test voltage	DC500～8kV; voltage accuracy: ±(5%+3 digits)
Device charging and discharging time	0.1s ~ 999.9S independently adjustable; its accuracy is ± 1%
Test capacitor capacity range	0～1μF, 10 ranges, manual switching
Number of tests	1～9999 times; accuracy ± 1 time; digital display; automatic shutdown when the number of operations reaches
Random matching	1. One safety test tool 2. Factory certificate, measurement certificate 3. Instructions for use, including main components 4. One set of debugging tools 5. One set of tool boxes
High voltage transformer capacity	1000VA
Protection function	Overload, short circuit
Working power supply	AC220V±10％，1KVA

RX-CBE9850 capacitor pulse voltage test device (new model)

According to the standard	GB_T 6346.14-2015, IEC 384-14: 2005, Clause 4.13, design and manufacture, test the overvoltage performance of capacitors; IEC384-14: 2005, GB/T 14472-1998 Appendix A, Figure A1 and Table A1 requirements;
Test voltage	DC500～8kV; voltage accuracy: ±(5%+3 digits)
Device charging and discharging time	0.1s ~ 999.9S independently adjustable; its accuracy is ± 1%
Test capacitor capacity range	0～1μF, 10 ranges, manual switching
Number of tests	1～9999 times; accuracy ± 1 time; digital display; automatic shutdown when the number of operations reaches
Random matching	1. One safety test tool 2. Factory certificate, measurement certificate 3. Instructions for use, including main components 4. One set of debugging tools 5. One set of tool boxes
High voltage transformer capacity	1000VA
Protection function	Overload, short circuit
Working power supply	AC220V±10％，1KVA

All reviews0

Zhipinhui after-sales service

Equipment after-sales policy:

*Equipment warranty period: One Year

*After sales hotline: 4008166687

1. Our company has assembled a team of experienced on-site engineers and senior technicians who can respond promptly to any equipment issues and provide after-sales maintenance.

2. Within one week of the delivery of the new product, our after-sales technical department staff will provide installation and after-sales training for the equipment at the customer's location based on the contact information and address provided by the customer.

3. All complaints related to product quality will be responded to within 1 hour. Within 3-5 hours within the province and 24-48 hours outside the province, the customer will arrive at the scene and determine the handling measures based on the complaint situation, and carry out after-sales maintenance.

4. To better address customers' difficulties and concerns, our company promises that all maintenance personnel will be on call.

5. Any costs related to product quality during the shelf life will be borne by our company.

6. During the warranty period, we will provide free repairs due to improper use by your side or natural environment. The materials and accessories used for repairs will only be charged at cost price.
