RXCBE9851 capacitor spontaneous combustion test bench (new model)

According to the standard	IEC60384-14, GB/T6346.14-2015 4.18 design, the capacitor under test is subjected to 20 discharges of an energy storage capacitor, after which the energy storage capacitor is discharged, the capacitor under test is charged to the voltage of Ui; the interval between each two discharges is 5s, and the self-ignition of the capacitor is tested.
Output DC high voltage	0～8000V, continuously adjustable, resolution 1V, digital display accuracy ±(5% reading + 30 characters)
Output AC voltage	AC0～800V, continuously adjustable, resolution 1V, digital display accuracy ±(1% reading + 5 characters)
AC filter network	According to standard configuration
Sample capacity	No more than 15uF
Pulse break time	1～9999s, adjustable, digital display, accuracy: ±(0.1s+3%)
User-provided	Test cotton yarn, 1000:1 high voltage probe, digital storage oscilloscope
Power supply	Single phase AC220V 10KVA


RXCBE9851 capacitor spontaneous combustion test bench (new model)

According to the standard	IEC60384-14, GB/T6346.14-2015 4.18 design, the capacitor under test is subjected to 20 discharges of an energy storage capacitor, after which the energy storage capacitor is discharged, the capacitor under test is charged to the voltage of Ui; the interval between each two discharges is 5s, and the self-ignition of the capacitor is tested.
Output DC high voltage	0～8000V, continuously adjustable, resolution 1V, digital display accuracy ±(5% reading + 30 characters)
Output AC voltage	AC0～800V, continuously adjustable, resolution 1V, digital display accuracy ±(1% reading + 5 characters)
AC filter network	According to standard configuration
Sample capacity	No more than 15uF
Pulse break time	1～9999s, adjustable, digital display, accuracy: ±(0.1s+3%)
User-provided	Test cotton yarn, 1000:1 high voltage probe, digital storage oscilloscope
Power supply	Single phase AC220V 10KVA
