ZH9907 water inlet solenoid valve performance and life test bench

1、Overview
The equipment is used for the performance and life test of the electromagnetic valve for washing machine water inlet according to the relevant requirements of QB/T 1291-1991 and enterprise standards. The equipment is controlled by a touch-integrated computer + PLC, etc. The PC program is responsible for data processing and logic control. It is easy to operate and flexible to adjust. The system can memorize, record, store and display test results. The equipment system can provide test conditions and can flexibly conduct comprehensive tests on electromagnetic valves. It is an ideal auxiliary testing equipment for home appliance manufacturers.

2、Technical parameters
2.1、Test object: solenoid valve (hereinafter referred to as water valve)
2.2、Control mode: PLC+15-inch touch integrated computer+program
2.3、Test station and mode: 10 lifespans + 1 performance
2.4、Connection time: 0~999999S adjustable
2.5、Interval time: 0~999999S adjustable
2.6、Life test water pressure test range: 0~1MPa adjustable, equipped with 1 water pump 0-1.6MPa variable frequency adjustable. Pressure test equipped with 1 booster pump 1~3.5MPa servo adjustable.
2.7、Water flow meter: range 0-30L/min, flow meter resolution 0.01L/min

ZH9907 water inlet solenoid valve performance and life test bench
1、Overview
The equipment is used for the performance and life test of the electromagnetic valve for washing machine water inlet according to the relevant requirements of QB/T 1291-1991 and enterprise standards. The equipment is controlled by a touch-integrated computer + PLC, etc. The PC program is responsible for data processing and logic control. It is easy to operate and flexible to adjust. The system can memorize, record, store and display test results. The equipment system can provide test conditions and can flexibly conduct comprehensive tests on electromagnetic valves. It is an ideal auxiliary testing equipment for home appliance manufacturers.

2、Technical parameters
2.1、Test object: solenoid valve (hereinafter referred to as water valve)
2.2、Control mode: PLC+15-inch touch integrated computer+program
2.3、Test station and mode: 10 lifespans + 1 performance
2.4、Connection time: 0~999999S adjustable
2.5、Interval time: 0~999999S adjustable
2.6、Life test water pressure test range: 0~1MPa adjustable, equipped with 1 water pump 0-1.6MPa variable frequency adjustable. Pressure test equipped with 1 booster pump 1~3.5MPa servo adjustable.
2.7、Water flow meter: range 0-30L/min, flow meter resolution 0.01L/min
