400-816-6687ZH6802 Solenoid Valve Life Test Bench
一、Overview
Applicable to the durability test of normal temperature/hot water inlet and outlet solenoid valves of water purification equipment.Meet the technical requirements specified in the standards such as "QB/T 4144 Reverse Osmosis Water Purifier for Household and Similar Purposes";
二、Technical parameters：
1、Workstations: 12 workstations (4 of which can also be used for wastewater valve testing. Products of the same type can be tested together, but products of different types cannot be tested together), the same pressure source, using a ball valve for input;
2、Water tank: 2 100L water tanks (one normal temperature water tank; one heated water tank, the temperature is adjustable. The water tank can be automatically switched according to the settings), material 304, thickness ≥1.2mm;
3、Test pressure: 0.05~0.8MPa
4、Water flow meter: 0.2-3L/min
5、Switch-on time: 0-9999s adjustable.
6、Disconnect time: 0-9999s adjustable.
7、Equipped with adjustable DC power supply, DC 0-60V adjustable.
ZH6802 Solenoid Valve Life Test Bench
一、Overview
Applicable
to the durability test of normal temperature/hot water inlet and outlet
solenoid valves of water purification equipment.Meet
the technical requirements specified in the standards such as "QB/T
4144 Reverse Osmosis Water Purifier for Household and Similar Purposes";
二、Technical parameters：
1、Workstations:
12 workstations (4 of which can also be used for wastewater valve
testing. Products of the same type can be tested together, but products
of different types cannot be tested together), the same pressure source,
using a ball valve for input;
2、Water tank: 2 100L water tanks (one
normal temperature water tank; one heated water tank, the temperature is
adjustable. The water tank can be automatically switched according to
the settings), material 304, thickness ≥1.2mm;
3、Test pressure: 0.05~0.8MPa
4、Water flow meter: 0.2-3L/min
5、Switch-on time: 0-9999s adjustable.
6、Disconnect time: 0-9999s adjustable.
7、Equipped with adjustable DC power supply, DC 0-60V adjustable.
