400-816-6687一、基本要求：适用于储水式电热水器和即热式电热水器的电控板可靠性测试。
二、技术参数：
1)测试工位(同源投入):24个，分两层，每层12个工位，其中两个工位分别外接
一个负载;
2)箱体温度范围:-40℃~+150℃，常用85℃;
3)温度波动度:≤±0.5℃;
4)温度均匀度:≤±2℃:
5)温度偏差:≤±1℃;
6)升降温速率:
(1)升温速率:3.0~5.0℃/min;降温速率:2~4.0℃/min(从90℃降温至-25℃，空载
条件下);
(2)湿度范围:20%-98%R.H(AT+25℃~+85℃)，常用 85%R.H:
(3)湿度误差:+2/-3%R.H(75%R.H 以上); ±5% R.H(75%R.H 以下);
(4)箱体风速(不可调):1.7~2.5m/s;
(5)以上指标均在环境温度≤30℃，常压，空载、无负荷条件下、距箱体内壁 1/6
三、空间内测试测得:
(6)箱体内尺寸:1200*800*1000:
(7)双级系统，锅炉加湿方式，水质纯静水，循环使用;
(8)产品测试范围:适用于2-8.5KW的储水式电热水器和即热式电热水器的电脑板;
(9)提供30 套2.5米左右高温硅胶线及夹具用做电控板测试连接线;
四、负载参数：
(1)输出电流:0-40A，可调，可显示在显示器;
(2)输出路数:2路,互不干扰，使用空开投入以适用于不同的产品范围;
(3)电源开关:打开设备电源开关;
(4)负载柜机箱:A3 烤漆板，非标定制，带脚轮，带散热风扇，机箱颜色符合甲方确
认的色系;
一、基本要求：适用于储水式电热水器和即热式电热水器的电控板可靠性测试。
二、技术参数：
1)测试工位(同源投入):24个，分两层，每层12个工位，其中两个工位分别外接
一个负载;
2)箱体温度范围:-40℃~+150℃，常用85℃;
3)温度波动度:≤±0.5℃;
4)温度均匀度:≤±2℃:
5)温度偏差:≤±1℃;
6)升降温速率:
(1)升温速率:3.0~5.0℃/min;降温速率:2~4.0℃/min(从90℃降温至-25℃，空载
条件下);
(2)湿度范围:20%-98%R.H(AT+25℃~+85℃)，常用 85%R.H:
(3)湿度误差:+2/-3%R.H(75%R.H 以上); ±5% R.H(75%R.H 以下);
(4)箱体风速(不可调):1.7~2.5m/s;
(5)以上指标均在环境温度≤30℃，常压，空载、无负荷条件下、距箱体内壁 1/6
三、空间内测试测得:
(6)箱体内尺寸:1200*800*1000:
(7)双级系统，锅炉加湿方式，水质纯静水，循环使用;
(8)产品测试范围:适用于2-8.5KW的储水式电热水器和即热式电热水器的电脑板;
(9)提供30 套2.5米左右高温硅胶线及夹具用做电控板测试连接线;
四、负载参数：
(1)输出电流:0-40A，可调，可显示在显示器;
(2)输出路数:2路,互不干扰，使用空开投入以适用于不同的产品范围;
(3)电源开关:打开设备电源开关;
(4)负载柜机箱:A3 烤漆板，非标定制，带脚轮，带散热风扇，机箱颜色符合甲方确
认的色系;
