400-816-6687RXCBE-9800D Pulse Capacitor Durability Test Device (2020 New)
1. According to IEC60384-14, GB6346.14-2015 4.14 design, GB4706.1-2005 Appendix F, GB/T 14472-1998 4.14 requirements, it adopts microcomputer control, can digitally set the test voltage, running time, test capacity, etc.; and digitally display the test voltage and current, and is equipped with multiple sets of compensation reactors, so that the durability test of large-capacity capacitors can be realized with a smaller power supply capacity.
2. Capacitance range: single capacity does not exceed 5μF, rated voltage ≤500V
3. Test voltage: AC 100~650V continuously adjustable, digital display accuracy ±1.5%FS
4. Pulse high voltage: 100~1000V continuously adjustable, digital display accuracy ±1.5%FS duration: 0.1s; accuracy: ≤±10%
5. Workstation: 10 groups, the maximum test capacity of each group does not exceed 12uF; the capacitance capacity of each workstation does not exceed 5uF, and the total capacity of the equipment does not exceed 120uF
RXCBE-9800D Pulse Capacitor Durability Test Device (2020 New)
1.
According to IEC60384-14, GB6346.14-2015 4.14 design, GB4706.1-2005
Appendix F, GB/T 14472-1998 4.14 requirements, it adopts microcomputer
control, can digitally set the test voltage, running time, test
capacity, etc.; and digitally display the test voltage and current, and
is equipped with multiple sets of compensation reactors, so that the
durability test of large-capacity capacitors can be realized with a
smaller power supply capacity.
2. Capacitance range: single capacity does not exceed 5μF, rated voltage ≤500V
3. Test voltage: AC 100~650V continuously adjustable, digital display accuracy ±1.5%FS
4. Pulse high voltage: 100~1000V continuously adjustable, digital display accuracy ±1.5%FS duration: 0.1s; accuracy: ≤±10%
5.
Workstation: 10 groups, the maximum test capacity of each group does
not exceed 12uF; the capacitance capacity of each workstation does not
exceed 5uF, and the total capacity of the equipment does not exceed
120uF
