400-816-6687 RX9922 Water Pressure Test Bench
一、Equipment overview：
The
water pressure test bench is manufactured by our company according to
the requirements of domestic and foreign customers and in accordance
with relevant national standards and industry standards.A set of testing
equipment independently developed using imported components and
programmable controllers.It can be used for burst test and pressure
resistance test of various pressure-bearing components of household
appliances.
This test bench can set the system test pressure within
60MPa through the operating panel or regulator.When the workpiece is
damaged, the test bench can automatically record the actual water
pressure of the damage, and automatically shut down the booster pump and
other live devices to shut down the entire system.
It has two
boosting functions, automatic and manual. The operation is simple, the
equipment is safe and reliable, and it is beautiful and convenient.
二、Main performance parameters:
1）Power supply: 220VAC 50Hz 2KW single phase
2）Working environment temperature: 25℃±15℃. Relative humidity: 45%~95% RH
3）Test pressure range 0.8～60MPa
4）Medium temperature Normal temperature
5）Working medium: clean water
6）High-pressure water pump: gas-liquid booster pump, maximum pressure 60MPa
7）After the test is completed, it has the function of automatic high-pressure emptying
RX9922 Water Pressure Test Bench
一、Equipment overview：
The water pressure test bench is manufactured by our company according to the requirements of domestic and foreign customers and in accordance with relevant national standards and industry standards.A set of testing equipment independently developed using imported components and programmable controllers.It can be used for burst test and pressure resistance test of various pressure-bearing components of household appliances.
This test bench can set the system test pressure within 60MPa through the operating panel or regulator.When the workpiece is damaged, the test bench can automatically record the actual water pressure of the damage, and automatically shut down the booster pump and other live devices to shut down the entire system.
It has two boosting functions, automatic and manual. The operation is simple, the equipment is safe and reliable, and it is beautiful and convenient.
二、Main performance parameters:
1）Power supply: 220VAC 50Hz 2KW single phase
2）Working environment temperature: 25℃±15℃. Relative humidity: 45%~95% RH
3）Test pressure range 0.8～60MPa
4）Medium temperature Normal temperature
5）Working medium: clean water
6）High-pressure water pump: gas-liquid booster pump, maximum pressure 60MPa
7）After the test is completed, it has the function of automatic high-pressure emptying
Zhipinhui after-sales service
Equipment after-sales policy:
*Equipment warranty period: One Year
*After sales hotline: 4008166687
1. Our company has assembled a team of experienced on-site engineers and senior technicians who can respond promptly to any equipment issues and provide after-sales maintenance.
2. Within one week of the delivery of the new product, our after-sales technical department staff will provide installation and after-sales training for the equipment at the customer's location based on the contact information and address provided by the customer.
3. All complaints related to product quality will be responded to within 1 hour. Within 3-5 hours within the province and 24-48 hours outside the province, the customer will arrive at the scene and determine the handling measures based on the complaint situation, and carry out after-sales maintenance.
4. To better address customers' difficulties and concerns, our company promises that all maintenance personnel will be on call.
5. Any costs related to product quality during the shelf life will be borne by our company.
6. During the warranty period, we will provide free repairs due to improper use by your side or natural environment. The materials and accessories used for repairs will only be charged at cost price.
