What are the components of the washing machine performance testing system

　　This device is developed based on GB/T4288-2018 "Household and Similar Use Electric Washing Machines". The system integrates electrical parameters, temperature, pressure, and flow rate, and can record the test process curve throughout the entire process. What are the components of the washing machine performance testing system? Let's see how Guangzhou Zhipinhui Electronic Technology introduces it.

The testing system collects the following test data for each testing station: power, voltage, current, cumulative electricity, water flow rate, temperature, and time.

1. Test voltage: 100-300V, accuracy level 0.5

2. Test current: 0~20A, accuracy level 0.5

3. Test power: 0-5 kW, accuracy level 0.5

4. Constant temperature and pressure water supply: The constant temperature and pressure water supply can be adjusted from 0.1 to 1.0 Mpa, and the temperature can be adjusted from room temperature to 55 ° C. It can also be connected to tap water, and tap water and constant temperature and pressure water can be switched to each other.
