What are the technical requirements for a power cord bending load testing machine

　　This testing machine is suitable for manufacturers and quality inspection departments to test small household appliances. Electrical connections such as hair dryers and hair clips, as well as electrical wires, are subjected to lifting and twisting tests. What are the technical requirements for the power cord bending load testing machine? Let's take a look at how Guangzhou Zhipinhui Electronic Technology introduces it.

1. Power supply AC220V/50Hz;

2. Bending angle: adjustable from 10 ° to 90 ° on both sides;

3. Bending speed: 10-60rpm (variable frequency speed regulation), default 60 times/min;

4. Load weight: Each workstation comes standard with one 5N, 10N, 20N, and 25N each;

5. Test station: 3 stations with 3 sets of fixtures;

6. Electrical load parameters: 3 independent adjustable loads, adjustable from AC0~40A, adjustable from AC0~300V (manually adjusted)

7. Test times: one total counter, three sub counters, adjustable from 0 to 999999;

8. Mechanical principle: The motor drives the crank slider on the gearbox to perform reciprocating motion
