What are the technical features of the automotive connector thermal cycle temperature rise test bench?

　The temperature rise test bench simulates various temperature environments that automotive connectors may encounter in actual use to detect their thermal cycle temperature rise characteristics. What are the technical features of the automotive connector thermal cycle temperature rise test bench? Let's see how Guangzhou Zhipinhui Electronic Technology introduces it.
　

　　1. Programmable current source: (AC/DC can be customized according to customer requirements) Maximum output voltage: not more than DC5v

Output constant adjustable test current: DC0~50~500.0A continuously adjustable (customizable)

Current display accuracy: soil (0.5% reading + 5 characters)

Test current stability: soil (1% set value + 5 characters)

2. Controller: Power on/off time: 1~99.99 minutes/hours Number of on/off times: 1~9999 times, with power off memory function, automatic shutdown when the number reaches

3. Temperature rise test:

Temperature measurement range: 0~260℃: accuracy soil 0.3% reading + 1℃; resolution: 0.1℃

Temperature measurement: 8 channels (including 1 point to measure ambient temperature)

Configure 8 channels to collect temperature data simultaneously
